MagiDeal MAX30100 Pulse Oximeter Heart Rate Sensor Module For Wearable Fitness Assistant Devices Electronic Running Equipment
Product description:
MAX30100 integrated pulse oximetry and heart-rate sensor. - An optical sensor, derives its readings from emitting two wavelengths of light from two LEDs. - Measuring the absorbance of pulsing blood through a photodetector. - Optimized for reading the data through the tip of one's finger. - The signal is processed by a low-noise analog signal processing unit and communicated to the target MCU through the mikroBUS I2C interface.
DHT21 AM2301 Digital-output relative humidity & temperature sensor/module,connect with single-bus-line Sensor
Product description:
DHT21 Digital-output relative humidity & temperature sensor/module,connect with single-bus-line Sensor AM2301 Digital Temperature & Humidity SensorDHT21 Digital-output relative humidity & temperature sensor/module,connect with single-bus-line Sensor AM2301, This temperature & Humidity sensor is a wired version of the DHT21, in a large plastic body. It is a basic, low-cost digital temperature and humidity sensor. It uses a capacitive humidity sensor and a thermistor to measure the surrounding air, and spits out a digital signal on the data pin (no analog input pins needed). Its fairly simple to use, but requires careful timing to grab data. All calibration, digital output, Completely interchangeable, Long distance signal transmission, Relative humidity and temperature measurement.
I2C RTC DS1307 RTC Real Time Clock Module for Raspberry Pi - Red
Product description:
The RTC module is specifically designed for Raspberry Pi. It communicated with Raspberry Pi through I2C bus. There is a Maxim DS1307 and CR1220 button cell on the board to keep the real time for a long time after the Raspberry Pi has it’s power down. Set a serial port, TTL convenient way online debugging。
Digital PAM8610 2*15 W Two Channel Stereo Class Dual Amplifier Board 12V
Product description:
This amplifier plate adopts the official standard circuit design. Chip selection used is the United States' imported Long Ding micro class D power amplifier chip. The power amplifier has a high efficiency, large power, in the case of 12V power supply and can provide an output 10W + 10W power.Also has overheat and over-current protection function.
Original Hiland DDS Function Signal Generator Module DIY Kit Pulse Sine Wave
Product description:
● Delicated high speed (HS) signal output up to 8MHz, ● DDS signal with variable amplitude and offset, ● DDS signals: sine, square, saw, rev saw ,triangle, ECG and noise, ● 2 x 16 LCD menu, intuitive 5 button keypad, ● Frequency adjusting steps: 1, 10, 1000, 10000MHz, ● Restoring last configuration after power up, ● Has two outputs-one for DDS signal and another for high speed aquare signal, ● Material: PCB + Electronic Components, ● Power Supply: +5V / +12V / -12V, ● Menu Displey: 2 x 16 LCD, ● HS Signal Frequency: 1, 2, 4, 8MHz, ● Red Board Size: 8 x 8cm / 3.15 x 3.15in (L * W), ● Screen Size: 6.5 x 1.5cm / 2.6 x 0.6in (L * W)
H-bridge Stepper Motor Dual DC Motor Driver Controller Board HG7881 For Arduino
Product description:
Onboard Two PCS HG7881 motor controller chip. Module can drive 2 DC motors simultaneously, or one 4-wire 2-phase stepping motor. Module input voltage: 2.5-12V. Has a continuous current of 800mA per channel output capacity. PCB size: 29.2 (mm) x23 (mm).
HM-10 BLE Bluetooth 4.0 CC2540 CC2541 Serial Wireless Module Android iOS Arduino
Product description:
- This small size Bluetooth 4.0 TTL transceiver module allows your target device communicate with your iPhone/iPAD, IOS 6 or Android 4.3 above devices.
- It's easy to use and completely encapsulated.
- You can set it as slave or master.
- You can use AT command set the baudrate.
- Ultra-low standby power consumption 90uA~400uA
- Coverage up to 60 meters
- Built in PCB antenna
- Power input: 3.6V-6V DC (Can not higher than 6V)
- Size: 43mm x 15mm
- Color: Blue
- Net Weight: 4g
KitsGuru Ibeacons Near-Field Positioning Module BLE4.0 KG219
Product description:
iBeacons near-field positioning module BLE4.0 iBeacon KG219
JDY-08 backplane Module Bluetooth 4.0 module BLE Module CC2541 module
Product description:
JDY-08 transmission module is based on Bluetooth 4.0 protocol standard, the working band is 2.4GHZ range, modulation mode for GFSK, the maximum launch power of 0db, the maximum launch distance of 80 meters, the use of TICC2541 chip design, support users through the AT command to modify the device name, service UUID, transmitting power, matching code and other instructions, convenient and quick use of flexible.
RDM6300 - 125K EM4100 RFID Card Reader Module
Product description:
RDM6300 125KHz cardreader mini-module is designed for reading code from 125KHz card compatible read-only tags and read/write card ● It can be applied in office/home security, personal identification, access control, anti-forgery, interactive toy and production control systems etc ● *RDM6300 is the update version of RDM630, it has higher sensitivity and longer read range ● The pins and output data is 100% compatible with old RDM630 module ● Support external antenna ● Maximum effective distance up to 50mm ● Less than 100ms decoding time ● Uart interface ● Support EM4100 compatible read only or read/write tags ● Built-in external bi-color LED and buzzer driver ● Small outline design
RDA5807M FM Stereo Radio Module RRD-102 V2.0 Wireless Pro for Arduino Tuner
Product description:
RDA5807M FM Stereo Radio Module is (FM Stereo radio Module) high sensitivity, low power consumption, ultra-small size of the FM stereo radio module.Using RDA Microelectronics of RDA5807M(or RDA5802NM), this circuit fewer external components, the noise factor is minimal. Small size, low power consumption, low cost, simple application, the use of a wide range of advantages.Is an easy-to-use and possessed highly cost-effective single-chip FM stereo radio module.
HX1838 Infrared Remote Control module NEC Code Infrared Remote Control
Product description:
Containing three 20cm DuPont line 1. Sensor uses HX1838, high sensitivity 2. Operating voltage 5V 3. Output form: Digital output Module Interface Description VCC: 3.3V-5V external voltage (can be directly connected to the 5v microcontroller and 3.3v microcontroller) GND: external GND IN: external microcontroller I/O port, I/O port has been designed 10K pull-up resistor Kit theory test distance of about 5-8 meters, but the practical application depends on the ambient factors you use, as well as the middle barrier (such as diaphragm, glass, obstructions or other material blocking), receiving head with HX1838 with power work instructions lights, receive 38K frequency any remote coding data! Package Content: 1 X IR Remote Control(not contain battery) . 1 X HX1838 remote module. 1 X 1838 Universal Receiving Head. 1 X 3Pin 20cm Dupont cable.
NRF24L01 Power adapter Free 3D model
Product description:
NRF24L01 Power adapter free 3D model Model in Solidworks 2016. Rendering in Keyshot. IGES and STEP also available. Power adapter for NRF24L01 to power using 5V and regulate a 3.3V for the NRF24L01. Model made using caliper and parts drawings. This model is for the NRF24L01 power adapter, but also embed the NRF24L01 model from Tristan Newman ("nRF24L01+ enhanced transceiver board") for a complete assembly of NRF24L01 and its power adapter.
Keyes KY-017 Mercury Switch Module For Arduino
Product description:
The Keyes Mercury Switch Module is a simple and effective motion detecting module. When your autonomous vehicle or robot is tilted the mercury ball inside the tube will move to complete an electrical circuit which will in turn send a signal to your Arduino control system.
Getech Mechanical Endstop Switch Module V1.2 Mechanical Limit Switch for 3D Printer Switch Ramps 1.4
Product description:
The mechanical endstop uses a lever switch to detect when it is activated. The switch is wired up so that when activated, it pulls the signal to LOW. There is also an LED on the board that will light up when the switch is activated.It uses a standard 4 pin, 100" pitch header and accepts a standard, old-style CD-ROM audio connector cable.
A6 GSM GPRS Module Quad Band SMS Voice 850/900/1800/1900 with Antenna
Product description:
GPRS module GSM module A6 \ SMS \ Speech \ board \ wireless data transmission adapter plate A6 Quad-band GPRS/GSM module, is one of the smallest cutting-edge products in the world.It adopts LCC package technology and offers the highest reliability and robustness.Depending on the ultra tiny configuration of 22.8×16.8×2.5mm and easier soldering process, it is capable of being embedded in almost all customer applications. Featuring an industrial-standard interface, A6 delivers GSM/GPRS performance for SMS, Data and Voice with extremely low power consumption and extended temperature.Extraordinarily compact size and integrated protocols ensure A6 easily meet the requirements of all M2M applications, including VTS, Industrial PDA, Personal Tracking,Wireless POS, Smart Metering and many other M2M applications.
Arduino Sound Sensor
Product description:
The Sound sensor module for the Arduino shown in the image above has the ability to detect different sizes of sound. This sensor can be used to for a variety of uses from industrial to simple hobby or playing around. In this tutorial, we are going to connect the Arduino sound sensor module to the LED so that the LED will light up every time the sensor detects sound.
SIM800L GPRS GSM Module MicroSIM card TTL Serial Port SIMCOM - HBK0004
Product description:
Module Model: SIM800L Quad-band 850/900/1800/1900MHz Used in GSM based projects, GPS based projects, Robotics projects, or 8051/AVR/ARM/PIC/Arduino/Raspberry-pi based projects GPRS multi-slot class12 connectivity: max. 85.6kbps(down-load/up-load) GPRS mobile station class B Controlled by AT Command Supports Real Time Clock Supply voltage range 3.4V ~ 4.4V Supports A-GPS Supports 3.0V to 5.0V logic level Low power consumption, 1mA in sleep mode
DDS Function Signal Generator Module DIY Kit Sine Square Sawtooth Triangle Wave
Product description:
Fitting of DIY, great for Arduino DIY project, exercise your hand and brain. Features: Delicated high speed (HS) signal output up to 8MHz. DDS signal with variable amplitude and offset. Fitting of DIY, great for Arduino DIY project, exercise your hand and brain. Features: Delicated high speed (HS) signal output up to 8MHz. DDS signal with variable amplitude and offset. DDS signals: sine, square, saw, rev saw , triangle, ECG and noise. 2 * 16 LCD menu, intuitive 5 button keypad; Frequency adjusting steps: 1, 10, 1000, 10000MHz. Restoring last configuration after power up. Has two outputs-one for DDS signal and another for high speed aquare signal. Power Supply: +5V / +12V / -12V. Specifications: Color: red Material: PCB Weight: 105g / 3.70oz Size: 10 * 10 * 2cm / 3.15 * 3.15 * 0.79in ( L * W * H ) Packing List: 1 * PCB board 1 * LCD screen 1 * Chip 5 * Button switches 1 * Crystals 1 * Adjustable resistance 2 * Potentiometers 2 * Connectors 2 * Capacitors 20 * Resistors
SIM 800A GSM GPRS MODULE WITH RS232 INTERFACE
Product description:
The SIM800A modem has a SIM800A GSM chip and RS232 interface while enables easy connection with the computer or laptop using the USB to Serial connector or to the microcontroller using the RS232 to TTL converter. SIM800A - GSM/GPRS module Designed for global market, SIM800 is a quad-band GSM/GPRS module that works on frequencies GSM 850MHz, EGSM 900MHz, DCS 1800MHz and PCS 1900MHz.
The SIM800A modem has a SIM800A GSM chip and RS232 interface while enables easy connection with the computer or laptop using the USB to Serial connector or to the microcontroller using the RS232 to TTL converter. SIM800A - GSM/GPRS module Designed for global market, SIM800 is a quad-band GSM/GPRS module that works on frequencies GSM 850MHz, EGSM 900MHz, DCS 1800MHz and PCS 1900MHz.
GSM SIM 800C Serial GSM Modem
Product description:
Works with standard AT Commands. MIC (MICP, MICN) = Differential Signal Pins Speaker (SPKP. SPKN) = Differential Signal Pins. BT_A = Bluetooth Antenna External pin (Works only if the firmware in updated) ADC = Analog to Digital Input pin STAT = Status Signal Pin RI = Ring indicator UART Pins: DTR, DCD, CTS, RTS, RXD, TXD.
Absolute Native Electronics Turbidity sensor, liquid suspended particles, turbidity detection module
Product description:
the output way: high / low signal - High : 5V ; Low : 0V
operating temperature : -30C - 80 C;
Storage temperature : -10 - 80 C
Weight : 55g
Size : 30mm * 20mm * 12mm
Temperature Sensor Module DC 3.3V-12V NTC-10K Thermistor Module for Arduino
Product description:
The temperature sensor test temperature,and the voltage comparison to detect the temperature. When the temperature is greater than the set point, the DO outputs are low. 2mm temperature sensor head, which line length is 15CM. The on-board processor has high accuracy, fast response and good quality. The board adjustable potentiometer has high sensitivity.
Current Sensor CT1207
Product description:
A current sensor is a device that detects electric current (AC or DC) in a wire, and generates a signal proportional to it. The generated signal could be analog voltage or current or even digital output. It can be then utilized to display the measured current in an ammeter or can be stored for further analysis in a data acquisition system or can be utilized for control purpose.
Sonoff AM2301 High Accuracy Temperature Humidity Sensor for Sonoff TH10 and Sonoff TH16 - Black
Product description:
Shell material: ABS plastic
Temperature: resistive sensor
Humidity: capacitive sensor
Operating temp. Range: -40℃~+80℃
Power supply: 3.1-5.5V DC
Color: Black
Weight: 14g
Measuring rage:
Temperature:-40℃~+80℃
Humidity:0~99.9%RH
Accuracy: in 25℃
Temperature: ±0.5℃
Humidity: ±3% RH (10 ... 90%RH)
MAX30100 Pulse Oximeter Heart-Rate Sensor Module
Product description:
The MAX30100 is an integrated pulse oximetry and heart rate monitor sensor solution. It combines two LEDs, a photodetector, optimized optics, and low-noise analog signal processing to detect pulse oximetry and heart-rate signals. The MAX30100 operates from 1.8V and 3.3V power supplies and can be powered down through software with negligible standby current, permitting the power supply to remain connected at all times.
OLatus ADC 0808/0809 INTERFACE BOARD (555 based in built clock) for RASPBERRY PI ARDUINO AVR PIC 8051 by OL ELECTRONICS
Product description:
ADC 0808/0809 Interface Board with inbuilt Clock provided in the circuit board. Easy to interface with Micro Controllers. Used for Analog to Digital Conversion.
ADC 0804 Sensor Interfacing Circuit
- Analog To Digital is a device that converts analog input to digital number proportional to the magnitude of analog input.
- The resolution of ADC is the number of discrete values it can produce over the range of analog input.
- Eight bit resolution ADC can output numbers in the range of 0 to 255 where as a 10 bit ADC will generate output in the range of 0 to 1023.ADC is used to read analog data from sensors like current sensor, light sensor, temperature sensor, pressure sensor etc. The converted digital output is then be used as input to the microcontroller for further logical processing.
- About the ADC 0804 Sensor interfacing circuit Board:
- ADC 0804 Sensor interfacing circuit board is simple to use and easy to configure.The on-board ADC0804 can read inputs from 2 different sources. Source selection can be done with the help of jumper link. More details are provided in User Manual.
- This board can be interfaced with any microcontroller board. Ensure to make common Ground connection between the microcontroller board and the ADC board.
- Connect regulated 5V DC as power input to the ADC board.
- Error Correction:
- The ADC can be configured from onboard variable resistance or from External analog source.
- For Internal Source Selection: Keep the jumper between center pin and INT I/P.
- For External Source Selection: Use Single Pin F-F connector provided. Connect it's ends between pins marked as INT I/P and EXT I/P.
- Due to the PCB layout error, shifting 2 pin jumper to other side will not select Ext I/P source, so follow above connections as described.
About ADC:
3.3V/5V RTC I2C DS3231/DS3231SN Real Time Clock Module for Arduino Raspberry Pi
- 100% Brand new and high quality!
- Can provide for arduino libraries and routines
- Use DS3231SN precision clock chip, built 32.768 crystal
- Can provide precise year, month, day, hour, minute, second, in the morning and afternoon data
- You can output 1Hz signal, a second output signal
- You can use the CR1220 coin cell holding travel time
- The pull-up resistor R1 R2 own welding on the I2C bus
- Small size 3cm in diameter
- Pin spacing 22.86mm
- Color: Blue
- Size: diameter 3cm
RTC IIC I2C IIC DS3231S
ADS1015 12-Bit ADC - 4 Channel with Programmable Gain Amplifier
DESCRIPTION:
For microcontrollers without an analog-to-digital converter or when you want a higher-precision ADC, the ADS1015 provides 12-bit precision at 3300 samples/second over I2C. The chip can be configured as 4 single-ended input channels, or two differential channels. As a nice bonus, it even includes a programmable gain amplifier, up to x16, to help boost up smaller single/differential signals to the full range. We like this ADC because it can run from 2V to 5V power/logic, can measure a large range of signals and its super easy to use. It is a great general purpose 12 bit converter.
The chip's fairly small so it comes on a breakout board with ferrites to keep the AVDD and AGND quiet. Interfacing is done via I2C. The address can be changed to one of four options (see the datasheet table 5) so you can have up to 4 ADS1015's connected on a single 2-wire I2C bus for 16 single ended inputs.
To get you started, we have example code for both the Raspberry Pi (in our Adafruit Pi Python library) and Arduino (in our ADS1X15 Arduino library repository) Simply connect GND to ground, VDD to your logic power supply, and SCL/SDA to your microcontroller's I2C port and run the example code to start reading data.
- WIDE SUPPLY RANGE: 2.0V to 5.5V
- LOW CURRENT CONSUMPTION: Continuous Mode: Only 150µA Single-Shot Mode: Auto Shut-Down
- PROGRAMMABLE DATA RATE: 128SPS to 3.3kSPS
- INTERNAL LOW-DRIFT VOLTAGE REFERENCE
- INTERNAL OSCILLATOR
- INTERNAL PGA
- I2C INTERFACE: Pin-Selectable Addresses
- FOUR SINGLE-ENDED OR TWO DIFFERENTIAL INPUTS
- PROGRAMMABLE COMPARATOR
- This board/chip uses I2C 7-bit addresses between 0x48-0x4B, selectable with jumpers
GPS Module NEO-6M w/ PPS (pulse per second) Signal & Ceramic Antenna
DESCRIPTION:
The Ubox NEO-6M gps engine on this board is a quite good one, with high precision binary output. It has also high sensitivity for indoor applications. The gps module have a battery for power backup and EEprom for storing configuration settings. The antenna is connected to module through ufl cable which allow for flexibility in mounting the gps such that the antenna will always see the sky for best performance. This make it powerful to use with cars and other mobile applications.
- Able to use GPS as a really accurate clock, this board provides a PPS (pulse per second) signal. This is a highly accurate clock pulse coming off a pin on the GPS that NTP can use. If you have such a GPS the resource below is a must read.
- Compact and excellent performance
- Micro USB port, you can use general mobile phone cable to connect this GPS module to your computer. No need USB-TTL, convenient for use
- Onboard ceramic passive antenna, able to search for the satellite in open area, and an external antenna is optional
- SMA port, convenient for connecting with the external active antenna, stronger satellite search ability
- A reserved TTL port, convenient for connecting to USB-TTL or external single chip microcomputer
- Back-up rechargeable battery
- UART TTL socket
- EEprom to save configuration settings
- Support hot start
- Supply voltage: 3.3V - 5V DC
- Operating current: 45mA
- Baud rates: 9600 (configurable from 4800 to 115200)
- Navigation update rate: 5Hz maximum (1HZ default)
- Capture time: Cool start: 27s (fastest)；Hot start: 1s
- Operating temperature range: -40 to +85°C
- Separated 18 X 18mm GPS antenna
- Dimension: 22 X 30 X 13mm
- Weight: 19g
MAX6675 Thermocouple Temperature Sensor Module Type K SPI Interface For Arduino
- Working voltage: DC5V
- Operating Current: 50mA
- the temperature measuring range: -200 C - 1300 C [Test procedure for 0-1023 C]
- the temperature measurement accuracy: 1.5 C
- the temperature resolution: 0.25 C
- the output mode: SPI digital signal
- with a fixed mounting holes for easy fixed installation.
- storage temperature: -50 ~ 150 C
- the module weight: 4g
- module size: 25mm * 15mm * 13mm
Mini L293D Motor Driver Module for Arduino
DESCRIPTION:
L293D is a monolithic integrated, high voltage, high current, 4-channel driver. With this chip you can control DC motors and power supplies of up to 25 Volts. The L293D chip is also known as H-Bridge. The H-Bridge is typically an electrical circuit that enables a voltage to be applied across a load in either direction to an output, e.g. motor.
- Input voltage: DC4.5-25V
- The chip can supply a maximum current of 600mA per channel
- 1.2A peak output current (non repetitive) per channel
- Over Temperature Protection
- Logical "0" input voltage up to 1.5 V (high noise immunity)
- Internal clamp diodes
- Length: 38mm
- Width: 35mm
- Height: 12mm
- Weight: 15g
Generic PZIN51001336 Imported Mt8870 Dtmf Voice Tone Decoder Module Telephone Audio Speech Decoding Module
DESCRIPTION:
onboard complex frequency decoder chip mt8870 voice input interface board onboard five led indicators for easy viewing output state the chip have been drawn mainly basic pin pcb size: 26. 5 (Mm) x24. 5 (Mm) note: pcb design, vcc pin and gnd pin are in the opposite position, please be caution. The vcc pin should be the gnd pin, and the gnd pin should be the vcc pin material: plastic color: blue and black package includes: 1x voice decoder module.
Nodemcu ESP32S, ESP3212, ESP-32S, ESP-3212, Wireless WiFi Bluetooth Module
DESCRIPTION:
Nodemcu ESP32 is already integrated antenna and RF balun, power amplifier, low-noise amplifiers, filters, and power management module. The entire solution takes up the least amount of printed circuit board area. This board is used with 2.4 GHz dual-mode Wi-Fi and Bluetooth chips by TSMC 40nm low power technology, power and RF properties best, which is safe, reliable, and scalable to a variety of applications.
- High performance-price ratio
- Small volume, easily embeded to other products
- Strong function with support LWIP protocol, Freertos
- Supporting three modes: AP, STA, and AP+STA
- Supporting Lua program, easily to develop
- Development Board: https://github.com/Nicholas3388/LuaNode
3000W Thyristor SCR Voltage Regulator Temperature Dimmer for Speed / Light(AC 220V)
- Input Voltage:220V AC
- Maximum Power:3800W
- Adjustable Voltage:0-220V AC
- AC frequencys:50-60Hz
- Size(LxWxH):Approx.60x44x69 mm
- Material:Plastic,metal
How to Use:
Connect this device with lamp or home appliance in a series connection,then rotate the knob for dimming,speed,voltage, temperature control.
Appliance:
Electric furnace,water heater,lamps,small motor,electric iron.etc
the details of the appliance:can appiy to the use of new two-way high-power thyristor,as the current up to 40A,a good solution to the heating wire resistance in the case of cooling is too small to cause over-current problems;can easily adjust the electricity The output voltage between 0 and 220 volts-any adjustment for the use of electrical appliances.Such as:furnace,water heaters,heat transfer, light dimming,small motor speed,electric iron thermostat and so on.So as to achieve dimming,thermostats,pressure effect. Less than 3800 watts of electrical power for large-scale electrical power has been used as much,so the home appliances in general,sufficient,or small factories. (Inductive or capacitive load power should be reduced, the voltage regulator is equipped with two-way high-power thyristor,potentiometers are with nuts,do not add any components to use,very convenient and practical.)
High Power 2000W Thyristor Electronic Volt Regulator Governor Speed Controller
Features:
There's really nothing more than than the quality of the material regulator Taobao best, design is the most perfect. The regulator is specially modified for precision motor control circuit via multi-turn potentiometer to adjust the minimum output voltage.
- Voltage: AC 220V
- Maximum power: 2000W
- Voltage Regulator: AC 50V (about 50V, according to vary slightly appliances) -220V
- Size: high temperature FR-4 circuit board
- The regulator Used materials:
- STMicroelectronics imported SCR, voltage up to 1200 volts.
- Are all high-voltage capacitors,
- All are metal film resistors,
- ST imported trigger diode,
- Precision multi-turn potentiometer,
- Taiwan's main potentiometer goods manufacturers,
- Material and both are fine, they are carefully selected to purchase a large number of.
- Carrying fins, buyers can get our hands on
Arduino GPS SD Accelerometer to log
The SD card, or Secure Digital card, is a non-volatile solid-state flash memory. Meaning if we disconnect power, it will retain its data. With an SD card we can expand Arduino's permanent storage by gigabytes. This is useful for applications that store large amounts of data such as data loggers. A 4GB SD card can be had for only $5.
POWERING THE SD CARD
The LC STUDIO SD card socket used in this project can be powered with 5V or 3.3V power sources. There is an LM1117 3.3V regulator on board which can handle 800mA of current. The Arduino can provide 3.3V directly but it's limited to 50mA. That's not enough to power the SD card. So I powered the SD card socket from the Arduino Uno's 5V pin which can handle over 500mA of current. The 5V pin on the SD card socket will pass through the LM1117 regulator and come out a 3.3V with a current ceiling of 800mAh.
Just because this SD card socket can be powered with 5V or 3.3V, we still can't connect 5V Arduino pins to the SD card socket's pins. We have to level-shift the Arduino's 5V signals to 3.3V before we can connect them to the SD card.
This is where the SN74AHC125 IC comes in handy. This IC can convert (level-shift) a total of 4 signals from 5V to 3.3V. This is perfect because for this project, I only need to convert 4 Arduino pins from 5V to 3.3V: three to the SD card socket and one to the LGS20031 GPS receiver which is also a 3.3V module.
ALTERNATIVES TO THE SN74AHC125
You can replace the SN74AHC125 with the more available CD4050. I recently bought 10 of those from Ebay for about $0.40 a piece. The CD4050 is not pin compatible with the SN74AHC125 but it's easy to use. You will find many useful wiring examples for the CD4050 on the web.
THE ARDUINO SD LIBRARY
The Arduino IDE comes bundled with an SD library that's easy to use. You can include the SD library in your Arduino program by selecting from the main menu: Sketch\Import Library\SD
The library also comes with ready to use example programs to get you up and running. You can open those example programs from main menu: File\Examples\SD then pick any of the 6 example sketches. If you have the SD card socket connected and an SD card inserted, those examples will work on the spot.
For this prototype, I am using an old XTREME MiniSD 1GB SD1 card with a standard SD adapter simply because I have one available. I did not run into any performance issues with this class and model. Most memory cards sold today are the faster SDHC variety.
Data Logger Module for Arduino Data Logging Recorder Shield - With SD CARD SLOT and Battery (Included)
Compatible with arduino UNO, Duemilanove, Diecimila, Leonardo or ADK / Mega R3 or higher. ADK / MEGA R2 or lower is not supported. Built-in 3.3V regulator is a reliable reference voltage, and a reliable operation, requires a lot of power to run the SD card Welded joints, circuits or sensors prototyping area. Real-time clock (RTC) to maintain the time, even when the arduino is unplugged. Backup battery lasted for many years SD card interface with FAT16 or FAT32 formatted card. 3.3V level shifter circuit to prevent damage to your SD card
DS1302 RTC Real Time Clock module with CR2032 Battery
Description :
The DS1302 trickle-charge timekeeping chip contains a real-time clock/calendar and 31 bytes of static RAM. It communicates with a microprocessor via a simple serial interface. The real-time clock/calendar provides seconds, minutes, hours, day, date, month, and year information. The end of the month date is automatically adjusted for months with fewer than 31 days, including corrections for leap year. The clock operates in either the 24-hour or 12-hour format with an AM/PM indicator.
- Real-time clock can calculate seconds, minutes, hours, days, weeks, months, years and make adjustment according to leap year
- 318 bit temporary data storage RAM
- serial I/O port minimize the number of pins
- The wide working voltage range is 2.0 5.5V.
- when the working current is 2.0V, less than 300nA
- when read / write clock or RAM, data can be transmitted through single byte or character group of multiple byte
- 8 pin DIP package or optional 8 pin SOIC package, which should be determined based on different surface assembly condition
- A simple 3 line interface.
- Compatible with TTL Vcc=5V.
- optional industrial temperature range :-40 +85
- This dual power tube is used on main power supply and backup power supply
DS3231 AT24C32 IIC Precision RTC Real Time Clock Memory Module (M)
Product Description
Description DS3231 is a low-cost, extremely accurate I2C real-time clock (RTC), with an integrated temperature-compensated crystal oscillator (TCXO) and crystal. The device incorporates a battery input, disconnect the main power supply and maintains accurate timekeeping. Integrated oscillator improve long-term accuracy of the device and reduces the number of components of the production line. Technical Specifications 1. Size: 38mm (length) * 22mm (W) * 14mm (height) 2. Operating voltage :3.3 - 5 .5 V 3. clock chip: high-precision clock chip DS3231 4. Clock Accuracy :0-40 Degree range, the accuracy 2ppm, the error was about 1 minute 5. Calendar alarm clock with two Programmable square-wave output 6. Real time clock generator seconds, minutes, hours, day, date, month and year timing and provide valid until the year 2100 leap year compensation 7. Chip temperature sensor comes with an accuracy of ± 3 Degree 8. Memory chips: AT24C32 (storage capacity 32K) 9. IIC bus interface, the maximum transmission speed of 400KHz (working voltage of 5V). 10. Can be cascaded with other IIC device, 24C32 addresses can be shorted A0/A1/A2 modify default address is 0x57 11. Wiring instructions (with Arduino uno r3 for example): 12. SCL ? A5 13. SDA ? A4 14. VCC ? 5V 15. GND ? GND
acs 712 20amp current sensor module 5amp, 20amp, 30amp
Micro SD TF Card Memory Shield Module SPI Micro SD Storage Expansion Board For Arduino (M) - SMALL
- Power supply:4.5V - 5.5V, 3.3V voltage regulator circuit board
- Positioning holes: 4 M2 screws positioning hole diameter of 2.2mm
- Control Interface: GND, VCC, MISO, MOSI, SCK, CS
- Support Micro SD Card, Micro SDHC card (high-speed card)
- Level conversion circuit: Micro SD card into the direction of signals into 3.3V, MicroSD card toward the direction of the control interface
- MISO signal is also converted to 3.3V, general AVR microcontroller system can read the signal
MOSFET Button IRF520 Tube Driver Module for Arduino ARM Raspberry Pi
- Platform: Arduino, MCU, ARM, raspberry pie
- Using original IRF520 Power MOS, you can adjust the output PWM
- Arduino drive up to 24V allows the load, such as LED lights, DC motors, miniature pumps, solenoid valves
- PWM dimming LED can be used to achieve stepless dimming, variable speed motor
- Ports: Digital Level
- Voltage: 3.3V, 5V
- Output load voltage :0-24V
- Output load current: <5A (1A above need to add heat sink)
- Color: Red with Blue
- Material: Plastic
NODE MCU ESP8266 BOARD AMICA CP2102 DEC 2016 l FIRMWARE PREINSTALLED
- Open-source
- Interactive
- Programmable
- Low cost
- Simple
- Smart
- WI-FI enabled
- Advanced API for hardware IO, which can dramatically reduce the redundant work for configuring and manipulating hardware.
- Code like arduino, but interactively in Lua script. Nodejs style network API
- Event-driven API for network applicaitons, which faciliates developers writing code running on a 5mm*5mm sized MCU in Nodejs style.
- Greatly speed up your IOT application developing process.
PCF8591 module AD DA conversion of analog to digital digital-to-analog converter
Product Description
PCF8591 module AD / DA conversion of analog to digital / digital-to-analog converter module temperature illumination acquisition The PCF8591 is a monolithic, single power supply, low power consumption, 8-bit CMOS data acquisition device. PCF8591 has 4 analog inputs, 1 analog output and 1 serial I2C bus interface. 3 address pins A0, PCF8591, A1 and A2 can be used for hardware address programming, allowing access to 8 PCF8591 devices on the same I2C bus, without additional hardware. In PCF8591 based on input and output of the address, control and data signal is through double bidirectional I2C bus to serial transmission. PCF8591 features include analog input, built-in track and hold, 8-bit conversion and 8-bit conversion. The maximum conversion rate of PCF8591 is determined by the maximum rate of I2C bus. Package Including 1pcs x module + 5pcs x dupont wire
rs232 to rs485 converter
USB2 to TTL Enclosed cable
A4988 Stepper Motor Driver
The A4988 is a complete micro stepping motor driver with built-in converter, easy to operate. The products can be in full, half, 1/4, 1/8 and 1/16 step mode of operation bipolar stepper motor, output drive performance up to 35 V and ± 2 A. A4988 includes a fixed off-time current regulator, the regulator can be in slow or mixed decay mode
DRV8825 Stepper Motor Driver
The DRV8825 stepper motor driver carrier is a breakout board for TI’s DRV8825 microstepping bipolar stepper motor driver. The DRV8825 features adjustable current limiting, overcurrent and overtemperature protection, and six microstep resolutions (down to 1/32-step). It operates from 8.2 – 45 V and can deliver up to approximately 1.5 A per phase without a heat sink or forced air flow (rated for up to 2.2 A per coil with sufficient additional cooling).
EasyDriver Stepper Motor Driver A3967
- The EasyDriver is a simple to use stepper motor driver, compatible with anything that can output a digital 0 to 5V pulse (or 0 to 3.3V pulse if you solder SJ2 closed on the EasyDriver).
- MS1 and MS2 pins broken out to change microstepping resolution to full, half, quarter and eighth steps (defaults to eighth).
- Compatible with 4, 6, and 8 wire stepper motors of any voltage.
- Adjustable current control from 150mA/phase to 750mA/phase.
- Power supply range from 7V to 30V. The higher the voltage, the higher the torque at high speeds.
- Size: 4.8cm x 2cm
OV7670 Camera Module With Fifo
- High sensitivity for low-light operation.
- Low operating voltage for embedded application.
- Standard SCCB interface compatible with I2C interface.
- With AL422 3M-Bits FIFO.
- Raw RGB, RGB (GRB4:2:2, RGB565/555/444),YUV(4:2:2) and YCbCr(4:2:2)output format.
- Support VGA, CIF and from CIF to 40 x 30 format .
- Vario Pixel method for sub-sampling.
- Auto Image Control: AEC, AGC, AWB, ABF, ABLC.
- Image Quality Control: Color saturation, hue, gamma, sharpness and anti-blooming.
16x2 LCD Display
- Brand new and high quality.
- LCD display module with Green blacklight.
- Wide viewing angle and high contrast.
- Built-in industry standard HD44780 equivalent LCD controller.
- Commonly used in: copiers, fax machines, laser printers, industrial test equipment, networking equipment such as routers and storage devices.
- LCM type: Characters
- Can display 2-lines X 16-characters.
- Operate with 5V DC.
LCD Module Nokia 5110
This is a low-cost monochrome LCD module comprised of 84x48 pixels that can be used to display rich graphic and text content. Though it's an industrial module, this LCD display is extremely easy to use. This module is a revision that accepts 3-5V input. So no extra level shifter is needed. To have full control, you just need 5 pins. And as a classic display module among open source communities, there are handful related tutorials available over the Internet. So there is no need to panic even if you just got your foot in the door. Cause Nokia 5110 LCD module was discontinued, this product is made of recycled screen. Blemishes may exist. Please be aware of that. Features Classic display for learning with bunch of tutorials Adequate to general projects Low cost Specifications Input voltage: 3-5V Size: 1.6" Backlight: blue
Adxl335 Module 3-axis Analog Output Accelerometer
The ADXL335 is a small, thin, low power, complete 3-axis accelerometer with signal conditioned voltage outputs. The product measures acceleration with a minimum full-scale range of ±3 g. It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration. This breakout board comes with an on-board voltage regulator and works at both 3.3V & 5V (3-5V)
Ethernet LAN Module ENC28J60 Network
This is a great module if you want to add an internet connection to your microcontroller projects. The board is based off of the popular ENC28J60 IC and handles most Ethernet network protocol requirements. Ethernet LAN Module for PIC/Atmel AVR/Arm ENC28J60-I/SO Ethernet chip module Network Interface: HanRun HR911105A Supply Voltage: 3.3 V Size: 50mm x 33mm x 18mm
Ethernet Module W5100
The Arduino Ethernet Shield connects your Arduino to the internet in mere minutes. Just plug this module onto your Arduino board, connect it to your network with an RJ45 cable (not included) and follow a few simple instructions to start controlling your world through the internet. As always with Arduino, every element of the platform – hardware, software and documentation – is freely available and open-source. This means you can learn exactly how it's made and use its design as the starting point for your own circuits. Hundreds of thousands of Arduino boards are already fueling people’s creativity all over the world, everyday. Join us now, Arduino is you!
- Requires an Arduino board (not included)
- Operating voltage 5V (supplied from the Arduino Board)
- Ethernet Controller: W5100 with internal 16K buffer
- Connection speed: 10/100Mb
- Connection with Arduino on SPI port
CP2102 Serial Converter USB 2.0 To TTL UART 6PIN Module
- Use SILABS’s CP2102 chip, performance is definitely more than made PL2303, encroaching FT232RL.
- Full board design, full-featured interface. With RXD TXD RST 3.3V 5V DTR DCD RI RTS CTS and other full-featured interface. Some boards can’t work with normal CP2102 boards because of the incomplete interface, now it is not a problem anymore.
- With 500mA resettable fuse designed to prevent users from burning power pick the wrong computer USB, this is a must. Get hold of the plate board computer motherboard burned more harm than good.
- With power indicator light.
- Directly computer USB interface design, you can not use the computer switch wiring or extension cords.
- Package includes five DuPont line, you can link directly target board. Convenient and flexible.
Solar Panel
- Available in -
- 2v 150mA
- 3v 150mA
- 6v 100mA
- 12v 250mA
ACS712 30A Current Sensor
The device consists of a precise, low-offset, linear Hall circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field which the Hall IC converts into a proportional voltage.
- The current sensor chips: ACS712ELC-30B;
- Pin 5V power supply, on-board power indicator;
- The module can be measured plus or minus 30 amps, corresponding to the analog output of 185 mV / A;
- There is no the detection current through, the output voltage is VCC / 2;
- PCB board size: 31 (mm) x13 (mm);
LM2596 DC-DC Buck Converter Step-Down Power Module
This is an LM2596 DC-DC buck converter step-down power module with high-precision potentiometer, capable of driving a load up to 3A with high efficiency, which can work with Freeduino UNO, other mainboards and basic modules. When the output current keeps greater than 2.5A (or output power greater than 10W), please add a heat sink on it.
- Module properties: non-isolated step-down module
- Mode of rectification: non-synchronous rectification
- Input voltage: 4V-35V
- Output voltage: 1.25-30V
- Output current: 3A (MAX)
- Size: 53mm * 26mm
- Input mode: IN+ input positive IN- input negative
- Output mode: OUT+ output positive OUT- output negative
XL6009 DC - DC DC Step-Up Module
- Module properties: unfenced step-up (BOOST)
- The input voltage: 3-32 v
- Continuous adjustable output voltage: 5v-35 v
- Input current: 4 a (Max), no-load 18 ma
- Module size: 44.7 (mm) x21.7 (mm)
- Input mode: IN + input level is, the IN - negative input
- Output mode: OUT + output level is, the OUT - output is negative
- Conversion efficiency: < 94% (the lower the pressure difference, the greater the efficiency)
- Output ripple: 50 mv (the bigger the higher the voltage, current and ripple)
XL4015 5A DC-DC Step Down Adjustable Power Supply Buck Module LED w/ Heatsink
This product is a 180 KHz fixed frequency PWM buck (step-down) DC/DC module,capable of driving a 5A load with high efficiency, low ripple and excellent line and load regulation.
- Input voltage range：4～38VDC(Note:input voltage not exceeding 38V)
- Output voltage range：1.25-36VDC adjustable
- Output current: 0-5A
- Output power: 75W
- High efficiency up to 96%
- Built in thermal shutdown function
- Built in current limit function
- Built in output short protection function
- Input reverse polarity protection: None (if required, high current diode in series with the input).
- L x W x H = 5.4*2.3*1.5 CM
- Usage:
- Adjust the “voltage potentiometer” so that the output voltage reaches the value you want.
- Use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the “current potentiometer” so that the output current reaches a predetermined overcurrent protection value. (For example, the meter displays the current value of 4A, then you can use the module to a maximum current of 4A)
- Connected to the load.
- Usage:
- Make sure you need to charge the battery float voltage and charging current; (if lithium parameters 3.7V/2200mAh, then the float voltage is 4.2V, the maximum charging current 1C, ie 2200mA)
- Under no-load conditions, adjust the “Voltage potentiometer” so that the output voltage reaches the float voltage; (if to 3.7V rechargeable lithium battery, the output voltage can be adjusted to 4.2V)
- Use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the “current potentiometer” so that the output current reaches a predetermined Charging current value.
- Charge turn lamp current factory default is 0.1 times the charging current; (Battery during charging current is gradually reduced, if the charge current setting is 1A, then when the charge current is less than 0.1A, blue lights turned off, the green light is on, which means that the battery is fully charged)
- Connected to the battery charge.
- (1,2,3,4 steps as: Output is unloaded, do not connect the battery)
- Usage:
- Adjust the “voltage potentiometer” so that the output voltage reaches the value you want.
- Use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the “current potentiometer” so that the output current reaches a predetermined LED operating current.
- Connect LED, work.
- (1,2 steps as: Output is unloaded, do not connect LED)
XL4015 (2) 5A Lithium Charger DC-DC Buck Converter Step-Down Power Module
- Input voltage range: 6～38VDC(Note:input voltage not exceeding 38V)
- Output Voltage range: 1.8-36VDC adjustable
- Output Current: 0-5A
- Output Power: 75W (More than 2A, please add a heat sink)
- High efficiency up to 96%
- Built in thermal shutdown function
- Built in current limit function
- Built in output short protection function
- Input reverse polarity protection: None (if required, high current diode in series with the input).
- L x W x H = 61.7*26.2*15 mm
- Weight: 20g
Applications:The DC/DC buck module applications the input voltage is higher than the output voltage of the buck field, such as battery, power transformer, DIY adjustable regulated power supply, LCD Monitor and LCD TV，portable instrument power supply，telecom/networking equipment,24V vehicle notebook power supply,industrial equipment buck. 12V buck to 3.3V, 12V buck to 5V, 24V buck to 5V,24V buck to 12V, 36V buck to 24V etc.
XL4015 5A DC-DC Step Down Adjustable Power Supply Buck Module LED w/ Voltmeter
5A 4V-38V XL4015 DC-DC Adjustable Step Down Module Voltmeter
Feature: Feature:The DC-DC Adjustable Step Down Converter Module has large power, high efficiency, low-ripple. With power indicator, on-board voltmeter. The voltmeter can calibrate automatically. The measure can be changed between input and output voltage, with indicator. The voltmeter can also be shutdown. The board uses connection terminal for easy wiring. Built in thermal shutdown function Built in current limit function Built in output short protection function
- Better than 2596, easy to 4A 50W, up to 75W adding heat sink
- Input voltage: 4V ~ 38V (not more than 38V)
- Output voltage: 1.25V ~ 36V (adjustable)
- Output current: 0A ~ 5A (recommended below 4.5A)
- Output power: recommended use below 75W (add heat sink when more than 50W)
- Operating temperature: -40°C ~ +85°C
- Operating frequency: 180KHz
- Conversion efficiency: Up to 96% (based on input and output voltage, current, pressure)
- Voltmeter range: 0V ~ 40V
- Voltmeter error: ±0.1V (NOTE: To ensure the accuracy, keep the input above 4.5V)
- Load regulation: S (I) ≤0.8%
- Voltage regulation rate: S (u) ≤0.8%
- Power indicator: Yes
- Short circuit protection: Yes (limit current 8A)
- Over temperature protection: Yes (shutdown output automatically after over temperature)
- Input Reverse Polarity Protection: None (cascade high current diode if required)
- Wiring: IN+/- Input, OUT+/- Output
- Size: 66 x 39 x 18mm
- 1. Onboard voltmeter shows that the output voltage, long press the right button 2 seconds to loosen, voltmeter, and the output voltage indicator light [OUT] synchronous flash, at this time into the output voltage regulation mode; Similarly, when the input voltage IN the voltmeter display, long press the right button 2 seconds to loosen, voltmeter, and the input voltage indicator light [IN] synchronous flash, at this time into the input voltage adjustment mode.
- 2. Light touch button on the right side, the voltage value is adding up a unit; Press the left button, minus a unit; Due to a unit of voltage is less than 0.1 V, so you need to press the 1-5 consecutive can see the voltmeter change 0.1 V, the concrete continuous button several times depends on the current display voltage, current shows that the higher the voltage, the fewer the number of press.
- 3. After the voltage adjustment, long press the right button for 2 seconds, release, to exit the output voltage calibration mode, all the parameters set to automatically power down saving.
- The DC/DC buck module applications the input voltage is higher than the output voltage of the buck field, such as battery, power transformer, DIY adjustable regulated power supply, LCD Monitor and LCD TV, portable instrument power supply, telecom/networking equipment, 24V vehicle notebook power supply, industrial equipment buck. 12V buck to 3.3V, 12V buck to 5V, 24V buck to 5V, 24V buck to 12V, 36V buck to 24V etc.
- Note: The input voltage should be more 1.5V than output!
150W DC - DC Boost Converter 12 - 35V / 6A Step - Up Adjustable Power Supply
High Quality 150W DC - DC Boost Converter 10-32V To 12- 35V / 6A Step-Up Adjustable Power Supply
- Module Properties: non-isolated step-up module (BOOST)
- Input voltage :10-32V
- Output voltage: 12-35V (adjustable)
- Output Current: 10A (MAX)
- Input Current: 16A (MAX) (Enhance heat dissipation for more than 10A)
- Output power: natural cooling 100W (MAX), enhanced heat dissipation 150W (MAX)
- Easy to drive 65W/90W dual-core notebook.
- Use a 12V battery drive 19V, 3.42A notebook, the module temperature about 45°c
- Conversion efficiency: 94% (measured at Input 16V to output 19V 2.5A)
- Output Ripple: 2% (MAX) 20M-bandwidth
- Operating Temperature: Industrial (-40°c to +85°c) (ambient temperature exceeds 40°c, lower power use, or to enhance heat dissipation)
- Full load temperature rise: 45°c
- No-load current: 25mA typical
- Voltage regulation: ± 0.5%
- Dynamic response speed: 5% 200uS
- Short circuit protection: Nil (Please Install fuses and protection circuits at Input port)
- Input Reverse Polarity Protection: Nil (Please use Series diode at the input port)
Keypad 4x3
Keypad 4x4
Joystick Module
- Standard interface and electronic building blocks
- 2.54mm (0.1 inch) pin interface leads
- Cross rocker as a two-way 10K resistor, with the rocker in a different direction
- Arduino DIY part
MAX7219 Dot Led Matrix Display
- To satisfy electronic DIY hobbyists, we has developed MAX7219 Dot Matrix Module. It uses the Max7219 chip which do a great job on saving of MCU I/O. It can not only control each point individually, but also can be extended without limitation to meet your requirements on LED Sign, Team Logo and so on.
- A single module can drive an 8 * 8 common cathode lattice
- Module Operating voltage: 5V.
- Module size: 5 cm long X 3.2 cm wide X 1.5 cm high
- With four screws hole, aperture 3mm
- Module with input and output interfaces
- Supports multiple modules cascade
ISD1820 Sound/Voice Board Recording
Voice record module is base on ISD1820, which a multiple-message record/playback device. It can offer true single-chip voice recording, no-volatile storage, and playback capability for 8 to 20 seconds. The sample is 3.2k and the total 20s for the Recorder.
- Operating mode selector switch
- LED indicates if the board is recording
- Record up to 64 seconds of audio
- All pins of the ISD1932 broken out to 0.1" headers
- Breadboard friendly
ISD1760 Sound/ Voice recording board
1. ISD1700 voice module description ISD1700 voice module is quickly become familiar with and master the ISD1700 series chips designed for a simple and practical circuit board. It applies to all ISD1700 series chip, with a simple, fully functional characteristics. Recording chip ISD1700 series is a highly integrated, high-performance chips. It can be multi-segment recording, sampling rate can be adjusted from 4K to 12K, the power supply can range from 2.4V to 5.5V. ISD1700 there was the new recording prompts, when a new recording after, LED back flash once every few seconds to alert users to new recordings. In addition there are four kinds of sound to prompt the user's operating results, such as start recording, stop recording, erase, erase all the next one and so on. Recording data is stored in the FLASH chip, without any compression, so there is a better sound quality and power storage. Chip has two independent audio signal input channel, microphone input and analog signal inputs. In independent key mode, when the operation is completed, a functional chip will automatically enter power-down mode to reduce power consumption. In SPI mode, the user can do more functions on the chip operation. If any memory address for playback on the analog channel configuration register (Analog PathConfiguration register, APC) for reading and writing. 2. Module Description 1>. Size: 5.2CM * 5.5CM; 2>. Power supply: 5V; 3>. Recording time: 6K at 75 seconds, 8K for 60 seconds;
ESP8266 ESP-01 Serial WiFi Wireless Transceiver SMD Module
ESP-01 ESP-8266 is an ideal choice for hobbyist to start experimenting with IOT. The dimension of this module is 25mm x 15mm, with simple pin connections (standard 2×4 pin headers), using serial TX/RX to send and receive Ethernet buffers, and similarly, using serial commands to query and change configurations of the WiFi module. ESP8266 ESP-01 Serial WIFI Transceiver Module is a cheap and easy way to connect to internet via WIFI to any microcontroller platforms like Arduino. You can use AT commands to connect to WiFi networks and open TCP/IP connections (without need to have TCP/IP stack running in microcontroller). The module(ESP-01) can work with AT command when used with Arduino, USB to TTL adaptor (FTDI USB module is recommended). Additional power supply might be needed to power up the board.With GCC toochain and SDK availability opportunities with ESP8266 as a IOT device is endless.
ESP8266 ESP-12E Serial WiFi Wireless Transceiver SMD Module
ESP8266-12E is an enhanced version ESP8266-12, improve peripheral circuitry increases impedance matching, the signal output is better, whether it is stable or anti-jamming capability, have been greatly improved! For users before selecting the ESP-12, it does not matter even if the product has been made, enhanced version is fully compatible with previous firmware, the pin has added six IO ports on the basis of the ESP-12, SPI leads. ESP8266 is a highly integrated chip designed for the needs of a new connected world. It offers a complete and self-contained Wi-Fi networking solution, allowing it to either host the application or to offload all Wi-Fi networking functions from another application processor.
EM-18 RFID Card Reader
This is a low frequency (125 KHz) RFID Reader with Serial Output with at range of 8-12cm. It is a compact unit with built in antenna and can be directly connected to the PC using RS232 protocol. This product is a kind of play and plug device with a reading range of 8 to 10 cm and can be availed in the following specifications.
- Voltage: 5 Vdc
- Current: < 50ma
- Operating Frequency: 125 kHz
- Read Distance: 8 to 10 cm
- Size: 32 mm (length), 32 mm (width), 8 mm (height)
- Serial Output
- Buzzer Indication
USBASP USBISP AVR Programmer ATMEGA 8
- Support for AVRDude
- Allows you to read or write the microcontroller EEPROM,firmware, fuse bits and lock bits
- Support for Linux, Mac OS X and Windows
- XP,7,8
- 5 KB/sec maximum write speed
- Software controlled SCK option to support targets with low clock speed (< 1.5MHz)
- 10 pin ISP interface
HM-10 BLE 4.0 Bluetooth Module
If you are in need of such a 4.0 BLE Bluetooth module, MCU can be set up,also can controlled by a remote Bluetooth device for setting,can transfer data, and can remotely control 10 PIO pins,so,the best choice is HM-10 bluetooth module. can replace HC-05, HC-06, HC-07 etc. Support Central and Peripheral mode switch, modify by AT commander. Support Remote control mode, remote device can control PIO pin or modify settings by AT commander when Connected. (such as Iphone4s/5 ipad, Note2 etc.) The Bluetooth UART RS232 serial Converter Module can easily transfer the UART data through the wireless Bluetooth, without complex PCB layout or deep knowledge in the Bluetooth software stack, you can combine this bluetooth module with your system:
- MCU, ARM or DSP systems.
- SOC systems.
- Personal Digital Assistants (PDAs)
- Computer Accessories
- Other systems your want to use under bluetooth functions.
EM-18 RFID Card Reader Module 125 KHz with Serial Output
This is a low frequency (125 KHz) RFID Reader with Serial Output with at range of 8-12cm. It is a compact unit with built in antenna and can be directly connected to the PC using RS232 protocol. This product is a kind of play and plug device with a reading range of 8 to 10 cm and can be availed in the following specifications.
- Voltage: 5 Vdc
- Current: < 50ma
- Operating Frequency: 125 kHz
- Read Distance: 8 to 10 cm
- Size: 32 mm (length), 32 mm (width), 8 mm (height)
- Serial Output
- Buzzer Indication
USB 2.0 to Serial RS232 TTL UART Converter Module Adaper - CP2102 based
Connect the USB A to B Cable to USB B socket of the module and USB port of the computer, install drivers and you will be assigned a COM port through which you can communicate as you do through a SERIAL port. You can easily communicate with microcontrollers / microprocessors from your computer through the module. If you need TTL pins for communication, you can find TX, RX and GND points on board, solder 3 berg sticks and connect it to TTL pins of microcontrollers for direct communication without DB9 connector (No need to use MAX232 / MAX3232 for RS232 to TTL conversion in this case) Supports Windows 8.1 / 8 / 7 / Vista / Server 2003 / XP / 2000 / 98SE / CE 6.0 / CE 5.0 Supports Max OS X / Mac OS 9 Supports Linux 3.x.x / 2.x.x. Baud rates: 300 bps to 1 Mbps. Byte receive buffer: 640 byte transmit buffer. Create virtual COM port and connect your old devices which use serial port communication Compatible with both 3.3V & 5V levels LED indication (ON only when port is opened and being used, otherwise OFF) Temperature Range: -40 to +85.
SIM900A GSM/GPRS Modem Module - Talky Version
- High Quality Product
- Uses SIM900A GSM Chip
- Dual-Band GSM/GPRS 900/ 1800 MHz
- 3V3 & 5V interface for direct communication with MCU kit
- Configurable baud rate
- SIM Card holder.
- Built in Network Status LED
- Normal operation temperature: -20 °C to +55 °C
- Input Voltage: 12V DC
- Also Work on Battery
- Battery Charging Facility
- Latest Audio Interface compatible with Ear Phone with mic.
- Debug Port with micro USB connector
USBASP USBISP AVR Programmer
- Allows you to read or write the microcontroller EEPROM,firmware, fuse bits and lock bits
- Support for Linux, Mac OS X and Windows XP,7,8
- 5 KB/sec maximum write speed
- Software controlled SCK option to support targets with low clock speed (< 1.5MHz)
- 10 pin ISP interface
20x4 Line LCD Display With backlight HD44780
This is a basic 20 character by 4 line display. Utilizes the extremely common HD44780 parallel interface chipset. Interface code is freely available. ' You will need ~11 general I/O pins to interface to this LCD screen. Includes LED backlight.
128x64 Graphical LCD Module (Green)
This is a graphical LCD 128x64 pixel with LED backlight. This unit is a very clear type LCD with a simple command interface.
PWM DC 6V 12V 24V 28V 3A Motor Speed Regulator Control Switch for DC Motors
This DC Motor Speed Controller allows controlling the direction of a DC motor using a Pulse-- Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 0%-100%. The motor speed controller can easily provide a continuous current of3A to your DC motor or other DC load.
- Input supply voltage:6V-28VDC
- The maximum output power: 80W
- The maximum continuous output current :3A
- Duty Cycle adjustable:5%-100%
- Quantity:1PC
- 1. Connect your DC motor (or DC load) to the motor terminals as indicated on the wiring diagram.
- 2. Connect a voltage of 10V-36V DC to the circuit making sure of the correct polarity of the connection. Note that the voltage applied to the motor will be supply voltage applied to the circuit. It is recommended to add an appropriately rated fuse inline with the positive supply in order to protect the circuit from any possible short circuits.
- 3. You can now control the speed of the motor through potentiometer.
DC Motor Speed Control Regulator Pulse PWM 12V-40V 10A
The DC Motor Speed Controller allows controlling direction of a DC motor using a Pulse-Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 0%-100%. The circuit also includes a 10A fuse, with reverse connection of power supply and control voltage over-voltage protection function.
12V 24V 48V 40A DC Motor Speed Regulator PWM HHO RC Controller 2000W
t's a PWM speed controller which enables you to control the speed of those DC brush motors smoothly. It's great for applications like car motors, DC heater, bulb etc. providing nice adjustment of motor speed. Features: Wide voltage range, 10-50V, 40A, max. 2000W for motor speed control & HOO. Apply PWM Modulation system to adjust motor speed from 5-100% . Stable in working, high efficiency and low noise. Field-effect tube, drive IC, 70μm copper sheet PCB for higher efficiency of PWM wave output. Potentiometer for speed adjustment, protective case creates better durability. Specific Power Control: 12V: 480W; 24V: 960W; 36V: 1440W;40V: 1600W; 50V: 2000W PWM Working Principle: BY changing the duty ratio of square wave(output) to adjust average current power from 0-100% on load, thus to change the motor speed or light brightness.
Micro USB 5V 1A 18650 Lithium Battery Charger Board With Protection Module
Charging module
Size: approx. 2.6 x 1.7cm/ 1.02″ x 0.67″
Input voltage: 5V
Charging cut-off voltage: 4.2V ±1%
Maximum charging current: 1000mA
Cell overdischarge protection voltage: 2.5V
Cell overdischarge protection current: 3A
Charging and protect circuit at the same time
LED indicator- red is charging Blue is fully charged
Micro USB female outlet for input end, can be used to charge the lithium battery by 5v charger directly.
Connect “B+”to positive electrode of battery and “B-” to the anode. Connect “Out+”and “Out-” to load.
W1209 -50~100 digital temperature controller thermostat switch
- Control range: -50 ~ 110
- Input Power: DC 12V
- Resolution: -9.9-99.9 0.1 , other temperature ranges 1
- Measuring inputs: NTC (10K 0.5%) Waterproof sensor 0.5M
- Measurement accuracy: 0.1
- Output range: 1 way 10A relay
- Control accuracy: 0.1
- Environmental requirements: -10-60 , humidity 20% -85%
- Hysteresis accuracy: 0.1
- Size: 48 * 40mm
- Refresh rate: 0.5S
- Power consumption: Static current: <= 35MA,attract current:<= 65MA
- Temperature protection :0-110
- Display Type: 0.28 ” three digital display tube
PN532 NFC Near Field Communication RFID V3 Module
- Control range: -50 ~ 110
- Small dimension and easy to embed into your project
- Support I2C, SPI and HSU (High Speed UART), easy to change between those modes
- Support RFID reading and writing, P2P communication with peers, NFC with Android phone
- RFID reader/writer supports:
- Mifare 1k, 4k, Ultralight, and DesFire cards
- ISO/IEC 14443-4 cards such as CD97BX, CD light, Desfire, P5CN072 (SMX)
- Innovision Jewel cards such as IRT5001 card
- FeliCa cards such as RCS_860 and RCS_854
- Up to 5cm~7cm reading distance
- On-board level shifter, standard 5V TTL for I2C and UART, 3.3V TTL SPI
- Arduino compatible, plug in and play with our shield
TEC1-12705 Heatsink Thermoelectric Cooler Cooling Peltier Plate Module
- 40mm x40 mm TEC1-12705 TEC Thermo Electric colling Generators Thermoelectric Peltier Cooler
- Chip Model: TEC1-12705
- Dimensions: 40 * 40 * 3.8mm,
- Component :Logarithm of 127
- Wire Size:Lead Length 100 5mm,RV standard wire,Single head 5mm Tin Plated
- Internal resistance: 2.4 ~ 2.7 (ambient temperature 23 1 , 1kHZ Ac test)
- Maximum temperature: Tmax (Qc = 0) :60
- Operating current: Imax = 12 (rated voltage startup)
- Rated voltage: DC12V (Vmax: 15.5V)
- Cooling power: Qcmax 30W
- Assembly Pressure: 85N/cm2
- Working environment: Temperature range -55 ~ 83 (high ambient temperature will directly affect the cooling efficiency)
- Storage conditions: -40 ~ 60
TEC1-12706 Thermoelectric Cooler Peltier module 12V, 92.4Watts
- Color: White
- Material: Plastic + ceramics
- Rated voltage: 12V
- Rated power: 50~72W
- Get ice cold in minutes or heat to boiling by simply reversing the polarity, used for numerous applications from CPU coolers to alternate power sources, or even for your own custom car drink warmer/cooler.
- These devices must be used in conjunction with a heat sink to avoid burned
- One side is cooling (Printed model number)and another side is heating (Printed no word) when working.
- Please radiating the heating side, avoid using under no-radiating condition over 2s\Coated with thermal grease when install the device
- Cable length: 30cm
- Dimensions: 1.57 in x 1.57 in x 0.12 in (4.0 cm x 4.0 cm x 0.3 cm)
TEC1-12715 12V DC 15 AMP, Semiconductor Thermoelectric Peltier Cooler Heater
A thermoelectric cooling (TEC) module is a semiconductor-based electronic component that functions as a small heat pump. By applying DC power source to a TEC, heat will be transferred from one side of the module to the other. It creates a cold and hot side. They are widely used in industrial areas, for example, computer CPU, CCDs, portable refrigerators, medical instruments, and so on.
- Model: TEC1-12715.
- Operates Temperature: -40degree to 90degree
- Operates from 0~15.4V DC and 0~15A
- Rated Voltage: 12V
- Rated Current: 15A
- Max power consumption: 165 Watts
- Material: Plastic + ceramics
- Color: White
- Get ice cold in minutes or heat to boiling by simply reversing the polarity, used for numerous applications from CPU coolers to alternate power sources, or even for your own custom car drink warmer/cooler.
- These devices must be used in conjunction with a heat sink to avoid burned
- One side is cooling (Printed model number)and another side is heating (Printed no word) when working.
- Please radiating the heating side, avoid using under no-radiating condition over 2s\Coated with thermal grease when install the device
- Cable length: 20cm
- Dimensions: 1.57 in x 1.57 in x 0.12 in (4.0 cm x 4.0 cm x 0.3 cm)
DS3231 AT24C32 IIC Precision RTC Real Time Clock Memory Module
DS3231 is a low-cost, extremely accurate I2C real-time clock (RTC), with an integrated temperature-compensated crystal oscillator (TCXO) and crystal. The device incorporates a battery input, disconnect the main power supply and maintains accurate timekeeping. Integrated oscillator improve long-term accuracy of the device and reduces the number of components of the production line
NE555 Pulse Frequency Duty Cycle Adjustable Module
- ize: 31mm * 22mm;
- Main chip: NE555;
- Input Voltage: 5V-15VDC. when power supply is 5V , the output current can be 15MA around;when 12V power supply, the output current can 35MA around;
- Input current: >=100MA
- Output amplitude: 4.2V V-PP to 11.4V V-PP. (Different input voltage, the output amplitude will be different)
- Maximum output current: >=15MA (5V power supply, V-PP greater than 50%), >=35MA (12V power supply, V-PP greater than 50%)
- Output with LED indication(low level ,LED will on; high level,LED will off;low frequency, the LED flashes);
- As a square wave signal generator,generates a square wave signal used for experimental development.
- Used to drive a stepper motor for generating a square wave drive signal.
- Generate adjustable pulse for MCU.
- Generate adjustable pulse,to control circuitry associated.
Rotary Decoder Encoder Module KY-040
The KY-040 Rotary Encoder Module, is an incremental electro-mechanical device that converts the angular position or motion of a shaft or axle to digital code. The output of incremental encoders provides information about the motion of the shaft, which is typically further processed in processor / controllers into information such as speed, distance, and position.
Speed Measuring Sensor Counter Motor Test Groove Coupler Module
Using imported groove optical coupling sensor, width 5mm. It have the output state light, if output high level, the lights are off. if output low level ,it on. If it covered,it will output high level;otherwise it output low level. Good signal and waveform, with strong driving ability for more than 15mA. The working voltage of 3.3V to 5V. Output: digital switch output (0 and 1). Equipped with a fixed bolt hole, easily install. Small board PCB size: 3.2 cm x 1.4 cm. Use the LM393 wide voltage comparer.
Vibration switch sensor module
This module features an adjustable potentiometer, a vibration sensor, and a LM393 comparator chip to give an adjustable digital output based on the amount of vibration. The potentiometer can be adjusted to both increase and decrease the sensitivity to the desired amount. The module outputs a logic level high (VCC) when it is triggered and a low (GND) when it isn’t. Additionally there is an onboard LED that turns on when the module is triggered.
- On-board LM393 voltage Comparator chip and Vibration sensing probe
- Support 5V/3.3V voltage input.
- On-board the output signal indication,output effective signal is high level, and the same time the indicator light up, output signal can directly connect with microcontroller IO.
- Signal detection sensitivity can be adjusted.
- Reserved a line voltage compare circuit. (P3 is leaded out).
- PCB size: 30(mm) x15(mm).
4 CHANNEL IIC I2C LOGIC LEVEL CONVERTER BI-DIRECTIONAL 5V to 3.3V ARDUINO BE0160
Product description:
If you've ever tried to connect a 3.3V device to a 5V system, you know what a challenge it can be. bi-directional logic level converter is a small device that safely steps down 5V signals to 3.3V AND steps up 3.3V to 5V at the same time. This level converter also works with 2.8V and 1.8V devices. What really separates this Logic level converter from our previous versions is that you can successfully set your high and low voltages and step up and down between them safely on the same channel. Each level converter has the capability of converting 4 pins on the high side to 4 pins on the low side with two inputs and two outputs provided for each side. The level converter is very easy to use. The board needs to be powered from the two voltages sources (high voltage and low voltage) that your system is using. High voltage (5V for example) to the HV' pin, low voltage (3.3V for example) to LV', and ground from the system to the GND' pin.
5CHANNEL FLAME SENSOR MODULE
Product description:
If you've ever tried to connect a 3.3V device to a 5V system, you know what a challenge it can be. bi-directional logic level converter is a small device that safely steps down 5V signals to 3.3V AND steps up 3.3V to 5V at the same time. This level converter also works with 2.8V and 1.8V devices. What really separates this Logic level converter from our previous versions is that you can successfully set your high and low voltages and step up and down between them safely on the same channel. Each level converter has the capability of converting 4 pins on the high side to 4 pins on the low side with two inputs and two outputs provided for each side. The level converter is very easy to use. The board needs to be powered from the two voltages sources (high voltage and low voltage) that your system is using. High voltage (5V for example) to the HV' pin, low voltage (3.3V for example) to LV', and ground from the system to the GND' pin.
5CHANNEL FLAME SENSOR MODULE
DESCRIPTION:
The item is able to detect the flame band respectively in the range of 700-1100 nm, short-wave near-infrared (SW-NIR), and is output via an electric signal (voltage signal).
FEATURES:
5 channel infrared flame sensor design, wide range of detection (the detection range of the ordinary single flame sensor is probably about 30°, as the distance increases, the range is gradually reduced, the detection range of the product is greater than 120°). Able to output a digital signal (high and low), easy to use. Able to output an analog signal (voltage signal), the measurement signal can be more accurately, the occasions for high precision. All five outputs status indicator, so whether debug or bring great convenience in the practical application of. Digital output detection distance adjustable. The analog output sensitivity adjustable, more flexible design. Using 1% resistor design, signal output is more accurate, suitable for the needs of high-precision measurement occasions. Onboard 3 M3 mounting holes for easy installation. 3.3V-9V power supply, and is compatible with most of the SCM system. The patch devices used in all SMT process automatic welding, military quality reliable.
ADXL345 3-Axis Digital Acceleration of Gravity Tilt Module for Arduino
Introduction
The ADXL345 is a small, thin, low power, 3-axis MEMS accelerometer with high resolution (13-bit) measurement at up to +/-16 g. Digital output data is formatted as 16-bit two’s complement and is accessible through either an SPI (3- or 4-wire) or I2C digital interface.
Features
- Supply Voltage: 2.0 - 3.6 VDC
- Ultra Low Power: As low as 23 uA in measurement mode, 0.1uA in standby mode at 2.5V
- SPI or I2C Communication
- Single Tap / Double Tap Detection
- Activity / Inactivity Sensing
- Free-Fall Detection
- The ADXL345 has special sensing abilities! The single and double tap sensing detects when a single, or two simultaneous, acceleration events occur. Activity and inactivity sensing detect the presence or lack of motion. Free-fall sensing compares the acceleration on all axes with the threshold value to know if the device is falling. All thresholds levels that trigger the activity, free-fall, and single tap/double tap events are user-set levels. These functions can also be mapped to one of two interrupt output pins. An integrated, patent pending 32-level first in, first out (FIFO) buffer can be used to store data to minimize host processor intervention.
- The ADXL345 is well suited to measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion or shock. Its high resolution (4 mg/LSB) enables measurement of inclination changes less than 1.0°. Furthermore, low power modes enable intelligent motion-based power management with threshold sensing and active acceleration measurement at extremely low power dissipation.
Applications
- Handsets
- Medical Instrumentation
- Gaming and Pointing Devices
- Industrial Instrumentation
- Personal Navigation Devices
- Hard Disk Drive (HDD) protection
- GND This pin must be connected to ground
- VCC Supply Voltage
- CS Chip Select
- INT1 Interrupt 1 Output
- INT2 Interrupt 2 Output
- SDO Serial Data Output (SPI 4-Wire) / I2C Address Select
- SDA / SDI / SDIO Serial Data I2C / Serial Data Input (SPI 4-WIRE) / Serial Data Input and Output (SPI 3-Wire)
- SCL/SCLK Serial Communications Clock
BEAM PHOTOELECTRIC SENSORS INFRARED SHOOTING COUNTING MODULE
PRODUCT DFESCRIPTION:
This module is used for intelligent vehicle, robots and other automated mechanical device to provide a versatile infrared detection system solutions. This is a groove type opto-coupler sensor which will output high 1 when an object is detected in the groove. Using imported groove optical coupling sensor, width 10mm. It have the output state light, if output high level, the lights are off. If output low level, it on. If it covered, it will output high level; otherwise it output low level.
SPECIFICATIONS:
- Main chip: LM393, on the radio-infrared head
- Working voltage: DC 5 Volt
- Single-channel signal output.
- Output valid signal is low.
- Work piece can be used for counting, motor speed.
- Output of the circuit board switch
- For debugging purposes, this module is equipped with on-board LED that will light up when the output terminal valued logic HIGH.
FEATURES:
- Use high quality Groove type opto coupler sensor
- Groove width is 10mm
- VCC GND OUT use 2.54mm standard pins to ease the connections.
- Has output status indication led, when output high TTL LED off, and vise versa.
- When objects in the groove output high TTL, vise versa.
- signal is reliable, good waveform, easy to drive, current over 15mA
- 3 mm screw drive hole, easy to mount it on somewhere
Applications:
- Motor speed detection
- Position detection
- Pulse counting
- Industrial applications
Precautions and Troubleshooting:
The supply to the sensor should be checked. The connection to the microcontroller should be checked. Not more than the operating voltage, supply should be given to the sensor.
DC Voltage Detector Sensor Module For Arduino
PRODUCT DFESCRIPTION:
- This module is based on principle of resistive voltage divider design
- Make the red terminal connector input voltage to 5 times smaller.Arduino analog input voltages up to 5 v,
- The voltage detection module input voltage not greater than 5Vx5=25V
- (if using 3.3V systems, input voltage not greater than 3.3Vx5=16.5V).
- Arduino AVR chips have 10-bit AD, so this module simulates a resolution of 0.00489V (5V/1023),
- The minimum voltage of input voltage detection module is 0.00489Vx5=0.02445V.
- Voltage input range : DC0-25 V
- Voltage detection range : DC0.02445 V-25 V
- Voltage analog resolution : 0.00489 V
- Output Interface : "+ " connected 5/3.3V, "-" connected GND, "s" connected Arduino AD pins
- DC input interface : red terminal positive with VCC, negative with GND
- By 3P connector, connect this module with the expansion of board Arduino,
- Makes it easier for you to detect voltage battery
- Material: Plastic
- Size: 2.6*1.4cm
END STOPPER
PRODUCT DFESCRIPTION:
Heat shrinkable end caps are typically used to seal cable ends and provide mechanical and environmental protection. When heated in excess of 121ºC (250ºF), SKE Heat Shrink Heavy Duty End Caps rapidly shrinks, forcing the melted adhesive lining to flow and cover the substrate. The adhesive forms a flexible bond with a wide variety of rubbers, plastics and metals. Upon cooling, the adhesive solidifies, forming a permanent, non-drying, flexible and water resistant barrier. Adhesive reflow will occur at temperatures above 80ºC (176ºF).
SPECIFICATION:
- Dimensions (0.79 x 0.24 x 0.59)" / (2.0 x 0.6 x 1.5) cm
- Weight 1.69 oz / 48 g
- Model KW-11-3Z
- Voltage AC 250V
- Current 5A
FEATURES:
- Potential free contacts
- Small size
- On board LED for NO and NC contacts
- durable in use
- Reliable performance, easy operation, flexible installation
- High effective and reliable to use
APPLICATIONS:
it has been widely used in LED lighting, communication Equipment electronic equipment, low noise and highs reliability.
ML8511 UVB UV (Ultraviolet) Rays Sensor Detector Breakout Test Module
PRODUCT DFESCRIPTION:
The ML8511 breakout is an easy to use ultraviolet light sensor. The MP8511 UV (ultraviolet) Sensor works by outputing an analog signal in relation to the amount of UV light that's detected. This breakout can be very handy in creating devices that warn the user of sunburn or detect the UV index as it relates to weather conditions. This sensor detects 280-390nm light most effectively. This is categorized as part of the UVB (burning rays) spectrum and most of the UVA (tanning rays) spectrum. It outputs a analog voltage that is linearly related to the measured UV intensity (mW/cm2). If your microcontroller can do an analog to digital signal conversion then you can detect the level of UV! Dimension: 13mm x 11mm x1mm
Package included:
1 x ML8511 UVB UV Rays Sensor Module
ML8511 UVB UV (Ultraviolet) Rays Sensor Detector Breakout Test Module
.jpg)
PRODUCT DFESCRIPTION:
PCF8591 AD / DA chip introduced PCF8591 is a monolithic. single supply. low-power. 8-bit CMOS data acquisition devices. PCF8591 has 4 analog inputs. one analog output and a serial I2C bus interface. PCF8591 of three address pins A0. A1 and A2 can be used for programming the hardware address. allowing access to eight PCF8591 devices on the same I2C-bus. without the need for additional hardware. Input and output on the PCF8591 device address. control and data signals through two-line bidirectional I2C bus serially transmitted. PCF8591 Key performance indicators: single power supply PCF8591 operating voltage range of 2.5V-6V
Low Standby Current via I2C-bus serial input / output PCF8591 by 3 hardware address pins addressing PCF8591 I2C bus speed sampling rate decision 4 programmable analog inputs for single-ended or differential inputs auto increment channel selection PCF8591 analog voltage range from VSS to VDD PCF8591 built-in track and hold circuit 8-bit successive approximation A / D converter DAC gain realized by an analog output
Two baby description A module chip PCF8951 2 module supports four external voltage input acquisition (voltage input range 0-5v) 3 modules integrated photoresistor. you can collect the ambient light intensity AD exact numeric 4 modules integrated thermistor. you can collect the ambient temperature exact numeric AD 5 module integrates a road 0-5V voltage input acquisition (via the blue potentiometer to adjust the input voltage) 6 modules with power indicator (on the module power indicator will light) 7 modules with DA output indicator. when the module DA output interface voltage reaches a certain value. it will light up the board DA output indicator. the greater the voltage. the LED brightness is more obvious; 8 module PCB size: 3.6cm 2.3cm 9 standard dual panel. thickness 1.6mm. nice layout. surrounded by a through-hole. pore size: 3mm. convenient fixed
Three module interface specification The module on the left and right. respectively. 2-way external expansion pin connector. respectively. as follows: DA output interface chip left AOUT AINO chip analog inputs 0 AIN1 chip analog inputs 1 AIN2 chip analog inputs 2 AIN3 chip analog inputs 3 The right of the clock SCL IIC interface connected microcontroller IO port SDA IIC digital interface connected microcontroller IO port GND module to external ground VCC power supply interface external 3.3v-5v
Four modules red cap shorted instructions There are three red module shorted cap. respectively. the following effects: P4 P4 shorting cap connected. select thermistor access circuit P5 P5 connected shorting cap. select photoresistor access circuit P6 P6 connected shorting cap. select 0-5V adjustable voltage access circuit
POWER LINE CARRIER MODULE KQ-430F
PRODUCT DFESCRIPTION:
Communication over Power Line. This module is design to communicate between two device through Power line (e.g 220V power line) without any extra components.
FEATURES
Working rate:120~135KHZ Interface baud rate:9600bps, the true baud rate is 100bps,250-byte buffer Temperature:-25 degree~+70 degree Humidity: 90% Power:DC +5V Receiver:11mA Transmitter:300mA Pin configuration
1P-AC: 220V AC voltage of the line of fire (or zero line) 2P-AC: 220V AC voltage zero line (or FireWire) 3P-+5 V: +5 V to send power (210mA), single income data can be vacant reduce power consumption The 4P-GND: Digital circuit ground 5P-+5 V: +5 V operating supply 11mA, the lowest operating voltage to 3.3V but not recommended 6P-RX: TTL level, carrier data into, then MCU TXD 7P-TX: TTL level, carrier data out, then the microcontroller RXD 8P-MODE: mode selection, vacant or connected to 5V high ground is low 9P-NC/RST: reset pin (active low) frequent switching mode. Do not need this feature, the pin should be left
Sliding Potentiometer Board Module Adjustable Slide Potential Instrument
Features:
- 100% Brand New and High Quality;
- Durable and practical sliding potentiometer;
- Stabilized moving order, easy and convenient to operate;
- Dual output, and linkage;
- Output 0-VCC simulation voltage signal
- Port: Analog Quantity
- Voltage: 303V, 5V
- Resistance Value: 10k
- Material: Plastic
- Color: Red+ Yellow+ Green+ Black+ White
- Size: 90 x 21 x 28mm (L x W x H)
Package Included:
1 x Sliding Potentiometer Module
WS2812 RGB LED Breakout Module RGB Module Display Module for arduino
Product Description:
This is a breakout board for the built in WS2812 RGB LED. The WS2812 is actually an RGB LED with a WS2811 builted right into the LED! All the necessary pins are broken out to 0.1" spaced headers for easy bread-boarding. Several of these breakouts can be chained together to form a display or an addressable string.
VOICE RECOGNITION MODULE V3 ARDUINO
Product Description:
We all know that there is a kind of module which can control the light on and off. You make a sound, the light turns on. Then after a while it turns off. This is not voice recognition. We may call it Sound Control. Voice recognition is something that knows exactly what you were saying.
We've beening thinking about a module which helps to control other devices by voice and it will not cost too much. Finally we designed this module. Well, what can this module do? It can recognize as much as 15 voice instruction, which is suitable for most cases involving voice control.
FEATURE
- Voltage: 4.5-5.5V
- Current: <40mA
- Digital Interface: 5V TTL level UART interface
- Analog Interface: 3.5mm mono-channel microphone connector + microphone pin interface
- Size: 30mm x 47.5mm
- This module can store 15 pieces of voice instruction. Those 15 pieces are divided into 3 groups, with 5 in one group. First we should record the voice instructions group by group. After that, we should import one group by serial command before it could recognize the 5 voice instructions within that group. If we need to implement instructions in other groups, we should import the group first. This module is speaker independent. If your friend speaks the voice instruction instead of you, it may not identify the instruction.
TCS3200 DETECTOR MODULE COLOR RECOGNITION SENSOR
Product Description:
The TCS3200 programmable color lighttofrequency converters that combine configurable silicon photodiodes and a currenttofrequency converter on a single monolithic CMOS integrated circuit. The output is a square wave (50% duty cycle) with frequency directly proportional to light intensity (irradiance).
The fullscale output frequency can be scaled by one of three preset values via two control input pins. Digital inputs and digital output allow direct interface to a microcontroller or other logic circuitry. Output enable (OE) places the output in the high-impedance state for multiple-unit sharing of a microcontroller input line.
FEATURE
- High-Resolution Conversion of Light Intensity to Frequency
- Programmable Color and Full-Scale Output Frequency
- Communicates Directly With a Microcontroller
- Single-Supply Operation (2.7 V to 5.5 V)
- Power Down Feature
- Nonlinearity Error Typically 0.2% at 50 kHz
- Stable 200 ppm/°C Temperature Coefficient
- Low-Profile Lead (Pb) Free and RoHS Compliant Surface-Mount Package
- TSC3200 Module x1
2x MAX7219 Dot Matrix MCU LED Display Control Module For Arduino Raspberry Pi in chennai
Product Description:
- A single module can drive a 8x8 dot matrix common cathode
- Operating Voltage: 5V
- Dimensions: 7.3X3X1cm
- Fixing screws with 64 holes with a diameter 3mm
- Module with input and output interfaces, support for cascading multiple modules
60 SECONDS VOICE RECORD – PLAYBACK MODULE in chennai
Product Description:
Voice Module 60 Sec project will playback and record up to 60 seconds of voice message. This circuit is an excellent choice to add voice to your project.
Specifications: Up to 60 Seconds of nonvolatile voice storageUp to eight segments record and play option availableEasy and clear, jumper selectable mode optionPreset for adjusting sampling rateTactile switches for Record, Play function triggerEasy jumper selection for selecting recording sourceOnboard microphone for recording message directly onto the chipAudio output available to drive a speakerDirect speaker connection via berg connectorLED to display Record/Playback of messagesBerg connector for power supply inputFour mounting holes of 3.2 mm eachPCB dimensions 54 mm x 94 mm This circuit will help you record and play a 60 seconds voice message stored on it. This circuit is based on APR9600 IC from Aplus.
The project provides four different modes of voice message to be recorded and played, viz i) MOD8 : 60 Seconds is equally dived in 8 equal segments, ii) MOD4 : 60 Seconds is equally divided in four equal segments, iii) MOD2 : 60 Seconds is equally divided in two equal segments and iv) Tape Mode : Entire 60 segment is available in a single shot mode. For MODE selection see MODE selection table.
There are two different ways to record a voice message onto the chip viz. i) CN1 connector on PCB for external audio input or ii) Onboard Microphone. Jumper J3 on the PCB to select audio source. J3-Position A would select the external audio input and J3-Position M/P would select onboard microphone. Onboard preset PR1 will adjust the sampling rate of playback and record option for IC. Important thing to remember is that, if you increase the sampling rate, the duration of message will reduce and vice-versa. For details see resistance values & sampling frequencies table.
Active Buzzer Alarm Module Sensor Beep for arduino smart car GM in chennai
Product Description:
"Product Specification Passive buzzer is characterized by: A passive internal sources without shocks, so if the DC signal can not make it with a tweet. Must 2K ~ 5K square wave to drive it 2 sound frequency controllable, you can make a ""more than a meter hair Suola Xi"" effect. 3 In some special cases, you can reuse a control and LED mouth Active buzzer is characterized by: An active internal buzzer with shock source, so long as a power will be called 2 program easy to control, SCM can allow a high and low sounds, while passive buzzer can not. One module description A module using 9012 transistor drive 2 Operating voltage 3.3V-5V 6 with fixed bolt hole for easy installation 7 small plates PCB size: 3.3cm * 1.3cm Two module interface specification (3-wire) 1 VCC external 3.3V-5V voltage (5v microcontroller and can be directly connected to 3.3v MCU) External GND 2 GND 3 I / O external microcontroller IO port Package Include 1 x Buzzer Sensor"
AMS1117 - 3.3V Power Supply Module in chennai
Key Features
- Input: DC 4.5V--7V
- Output: 3.3V, 800mA (load current can not exceed 800ma)
- Dual-panel design,
- Specially designed two rows of needle fixing holes can be fixed directly in the tunnel for the board to extend the experiment;
- 2P single row pin input and output for easy connection;
- PCB board size: 2.5cm * 1.1cm
- With power indicator (red)
AMS1117 1.2V Power Supply Module in chennai
Specifications:
- Input: DC 4.5V--7V
- Onboard AMS1117-1.2 chip
- Input voltage range of 4.75V-7V (Input voltage should be higher than the output voltage by 1V)
- Output: 1.2V, 800mA (load current can not exceed 800ma)
- Onboard power indicator to indicate power is turned on: Red LED
- 2P single row pin input and output for easy connection
- Output voltage interface, connection to facilitate the experimental
- Board size: 2.5cm x 1.1cm approx
- Dual-panel design, the layout is nice
AMS1117 1.8V Power Supply Module in chennai
Specifications:
- Input: DC 4.5V--7V
- Onboard AMS1117-1.8 chip
- Input voltage range of 4.75V-7V (Input voltage should be higher than the output voltage by 1V)
- Output: 1.8V, 800mA (load current can not exceed 800ma)
- Onboard power indicator to indicate power is turned on: Red LED
- 2P single row pin input and output for easy connection
- Output voltage interface, connection to facilitate the experimental
- Board size: 2.5cm x 1.1cm approx
- Dual-panel design, the layout is nice
Arduino Telephone Keypad in chennai
BMP180 High Precision Digital Barometric Pressure Sensor Board Module Arduino in chennai
1 x BMP180 High Precision Digital Barometric Pressure Sensor Board Module Arduino The BMP180 is a high-precision pressure sensors, small size, low power consumption, and can be used on mobile devices Its excellent performance and lowest absolute precision can reach 0.03hPa, and extremely low power consumption, only 3 μA BMP180 hosts using powerful 8-pin ceramic Leadless chip (LCC) ultra thin package, you can via the I2C bus directly connected to the microprocessor
Main features:
- Input: DC 4.5V--7V
- Pressure range: 300~1100hPa (elevation 9000 m ~-500 m)
- Power supply voltage: 1.8V~3.6V (VDDA), 1.62V~3.6V (VDDD)
- LCC8 package: lead-free ceramic carrier package (LCC)
- Size: 3.6mmx3.8x0.93mm
- Low power consumption: 5 µA, in standard mode
- High accuracy: low-power mode, the resolution of 0.06hPa (0.5 m)
- High linearity mode, resolution of 0.03hPa (0.25 m)
- With temperature output
- I2C interface
- Temperature compensation
- Lead-free, in line with the RoHS standard
- MSL 1-response time: 7.5ms
- Standby current: 0.1 μA
- No external clock circuit
Typical applications:
- Input: DC 4.5V--7V
- Precise GPS navigation (dead reckoning, bridge testing, etc)
- Indoor and outdoor navigation
- Leisure, sport and health monitoring
- Weather forecast
- Vertical speed indicator (rising/sinking speed)
- The fan power control
Breadboard Power Supply Module 3.3V5V in chennai
Main features:
- Breadboard power supply module, with 5 V, 3.3 V output voltages; Apply to MB102 Standard breadboard
- Input voltage: 6.5-12 V (DC) or 5V USB power supply
- Output voltage: 3.3V and 5V can switch over
- Maximum output current: <700 ma; Input voltage ON/OFF switch
- Independent control of upper and Lower Bread Board Power Rails. Can switch over to 0 V, 3.3 V, 5 V using jumpers on any rail. ; On-board two groups of 3.3V, 5V DC output plug pin, convenient external lead use.
DC0-25 Voltage Detector Sensor Module Board 3P Connector DIY For Arduino in chennai
.JPG)
Description:
- This module is based on principle of resistive voltage divider design
- Make the red terminal connector input voltage to 5 times smaller.Arduino analog input voltages up to 5 v,
- The voltage detection module input voltage not greater than 5Vx5=25V
- (if using 3.3V systems, input voltage not greater than 3.3Vx5=16.5V).
- Arduino AVR chips have 10-bit AD, so this module simulates a resolution of 0.00489V (5V/1023),
- The minimum voltage of input voltage detection module is 0.00489Vx5=0.02445V.
- Voltage input range : DC0-25 V
- Voltage detection range : DC0.02445 V-25 V
- Voltage analog resolution : 0.00489 V
- Output Interface : "+ " connected 5/3.3V, "-" connected GND, "s" connected Arduino AD pins
- DC input interface : red terminal positive with VCC, negative with GND
- By 3P connector, connect this module with the expansion of board Arduino,
- Makes it easier for you to detect voltage battery
- Material: Plastic
- Size: 2.6*1.4cm
EM18 125Khz RFID Reader Module in chennai
M485 5V Heartbeat Sensor Senser Detector Module By Finger For Arduino in chennai
This sensor module has 6 IR LED/phototransistor pairs mounted on a 0.375" pitch, making it a great detector for a linefollowing robot. Pairs of LEDs are arranged in series to halve current consumption, and a MOSFET allows the LEDs to be turned off for additional sensing or power-savings options. Each sensor provides a separate analog voltage output.
Description
100% brand new and high quality. Pulse monitor works as follows: The LED is the light side of the finger, and photo transistor on the other side of the finger The device also can be used as a signal generator for electric speed controller (ESC), then you can test your motor system without using a transmitter and receiver. Photo transistor used to obtain the flux emitted, when the blood pressure pulse by the finger when the resistance of the phototransistor will be slight changed Choosing a very high resistance resistor R1, because most of the light through the finger is absorbed,it is desirable phototransistor sensitive enough. Resistance can be selected by experiment to get the best results. The most important is to keep the shield stray light into the phototransistor. For home lighting that is particularly important because the lights at home mostly based 50HZ or 60HZ fluctuate, so faint heartbeat will add considerable noise
Laser Module Aruino SIVY(Blue ) in chennai
Product Description
This product in the display is a laser module from the house of Sivy. It is made of metal and comes in blue color. It comes with the dimension of 4.5 cm x 2.5 cm x 4 cm. Package includes: 1 unit.
Metal Detector in chennai
Description:
- Metal Detector with speaker and ttl output.
- Features And Usage
- VCC 9v battery
- Logic high out put with common ground.
- Can detect any metal at the range of 1cm to 3cm. you can connect 9v battery to make it handy. Note: it will not detect coins if it is in the middle of the coil, it may detect if it is close to the coil. it will not detect any type of explosives.
MMA7455 inclinometer Accelerometer Sensor Module Digital for Arduino,SPI I2C in chennai
Description:
- Features
- Digital Output: SPI / I2C
- Low Power Consumption
- Compact accelemotor / inclinometer
- 5V/3.3V input support
- PCB board double-sided gold-plated
- Size: 24.9 (mm) x12.8 (mm)
- Onboard RT9161 chip power
- Lower pressure drop than the 1117
- Faster load the appropriate speed
- Ideal for noisy power environment
- Pin Standard 100mil (2.54mm)
- Easily connect to development board such as
- Arduino with Sensor Shield
- LC AT91SAM7S Series ARM7 core board AVR mini or core series board and more
TSL2561 Luminosity Sensor Breakout infrared Light Sensor integrating Sensor in chennai
Description:
100% New brand and high quality The TSL2561 Luminosity Sensor Breakout is a sophisticated light sensor which has a flat response across most of the visible spectrum. Unlike simpler sensors, the TSL2561 measures both infrared and visible light to better approximate the response of the human eye. And because the TSL2561 is an integrating sensor (it soaks up light for a predetermined amount of time), it is capable of measuring both small and large amounts of light by changing the integration time. The TSL2561 is capable of direct I2C communication and is able to conduct specific light ranges from 0.1 - 40k+ Lux easily. Additionally, the TSL12561 contains two integrating analog-to-digital converters (ADC) that integrate currents from two photodiodes, simultaneously. Each breakout requires a supply voltage of 3V and a low supply current max of 0.6mA.
Specifications:
- Board Size: 1.7x1.3cm(approx) Color: As shown in the picture
TTP223B Digital Touch Sensor capacitive touch switch module in chennai
Description:
Low power consumption Power supply for 2 ~ 5.5V DC Can replace the traditional touch of a button Four M2 screws positioning holes for easy installation -Control Interface : A total of three pins (GND, VCC, SIG), GND to ground , VCC is the power supply , SIG digital signal output pin ; -Power Indicator : Green LED, power on the right that is shiny ; -Touch area : Similar to a fingerprint icon inside the area , you can touch the trigger finger . -Positioning holes : 4 M2 screws positioning hole diameter is 2.2mm, the positioning of the module is easy to install , to achieve inter- module combination ;
MMA7455 inclinometer Accelerometer Sensor Module Digital for Arduino,SPI I2C in chennai
Description:
- Features
- Digital Output: SPI / I2C
- Low Power Consumption
- Compact accelemotor / inclinometer
- 5V/3.3V input support
- PCB board double-sided gold-plated
- Size: 24.9 (mm) x12.8 (mm)
- Onboard RT9161 chip power
- Lower pressure drop than the 1117
- Faster load the appropriate speed
- Ideal for noisy power environment
- Pin Standard 100mil (2.54mm)
- Easily connect to development board such as
- Arduino with Sensor Shield
- LC AT91SAM7S Series ARM7 core board AVR mini or core series board and more
8 LED Full Color 5050 RGB LED Module(WS2811) in chennai
Description:
Keyes Wearable 2812 8 LED Full Color 5050 RGB LED Module It's now time to accessorize your wardrobe. Add some lights to your clothing and provide blinking bling, dancing patterns or mood lighting. Customize the lights from your wearable project. They can also be used to keep you visible and safe if jogging or cycling at night. Keyes WS2812 is an intelligent control LED light source that the control circuit and RGB chip are integrated in a 5050 SMD component. This module comes as a strip and has 8 LEDs.
Specs:
- Number of LEDS: 8
- Dimensions: 54x10x3mm
- Weight: 3g
Capacitive Touch LED Dimmer PWM Control Switch Module - KG371 arduino in chennai
Product description:
The lamp brightness can be adjusted by requirement.it is very to operate. It can touch in medium protection.such glass.acrylic.plastic.ceramics and so on.which is very safe. Wide application of voltage range.you can choose arbitrarily between 2.4V to 4.5V. Simple applied circuit.less peripheral devices. easy processing. low cost. Anti power and phone interference.the EFT can reach above +/-2KV;the touch response sensitivity and reliability will not affected by the close distance or multi-angle mobile phone interference. Install:Needn’t to touch copper foil directly.the dimming can be processed across acrylic glass(above 3mm) or plastic. Application:It can control LED module.light and so on.It is available for indoor LED.lighting lamp.DIY automotive lights dimming refit. Function:Single touch.using the principle of capacitance touch .The default function is switch.dimming.with brightness memories LED touch dimming.It will light slowly when turn on the lights.and become dark slowly when turn off.which effectively avoid the stimulation to eyes. Dimming mode:Non-polar PWM dimming. Wiring method:PCB board(VCC.GND) is power input.(LED+. LED-) is connected with the LED lamps of positive and negative level (fingerprint) touch area. also can wire to lead out (the wiring should not be too long). copper skin area should be 2x3cm.With copper foil copper foil board module will side to the shell side. Using method Click touch(touch duration time is less than 550ms) can control the lamp.Click once. the lamp lights;click again.the lamp off.The initial brightness of lights lit the fixed for the whole brightness of 90%. Press the touch at long time (touch duration time is more than 550ms). you can achieve stepless dimming the lights. Press long time once. light levels gradually increase light levels when released after the release time parked in the corresponding brightness. long time if more than three seconds. the light levels to achieve maximum brightness does not change; again long press touch. light levels gradually decreased to stop when you release the light levels in the corresponding brightness release time. if a long time more than three seconds. the light levels after reaching the minimum brightness does not change.
Technical characteristics::
- TI touch input corresponds to the LED lighting control output. There are four optional functions.decided by the T1 and T2 pins input state before power. The details are as follows:
- T1=1.T2=1:Without brightness memory.suddenly light and off LED touch Stepless dimming function.
- T1=0.T2=1:Without brightness memory.gradually light and off LED touch Stepless dimming function.
- T1=1.T2=0:With brightness memory.gradually light and off LED touch Stepless dimming function.
- T1=0.T2=0:LED three sections touch dimmer function.
- Without brightness memory.gradually light and off LED touch Stepless dimming function are as follows:
- Initial power. lamp is in off state.
Click the touch (touch duration less than 550ms). can control the lamp. One click touch. light; click again.off.When the lamp is light or off.there is no brightness buffer. And the initial brightness of light is 50% of the whole brightness. Long press the touch (touch duration more than 550ms). and can realize stepless brightness adjustment of the light. A long press the touch. the brightness of the light gradually increased. when loosening the brightness of the light brightness corresponding to stop in loosen the moment. if long in time for more than 3 seconds.then the brightness of the light to reach the maximum brightness and then don't change; again. long in the touch. the brightness of the light gradually decreased. when loosening the brightness of the light brightness corresponding to stop in release time. if the long according to the time for more than 3 seconds. then the brightness of the light to reach the minimum brightness after no change.
Click on the touch and long press the touch can be used at any time. between each other without interference and restriction function. Without brightness memories dimmed LED touch stepless dimming function is based on the without memory without brightness memory.gradually light and off LED touch Stepless dimming function.click on touch lights going on and off. by making the light by a lower brightness slow smooth transition to turn on the lights in the initial brightness. when click off touch. make the light by the current brightness slowly and smoothly reduced until off. so as to achieve the visual buffer effect of brightness changes slowly. to protect the eyes and vision. LED three sections touch dimmer function Initial power. lamp is in off state. Each time you click the touch. the brightness of the light is changing circulatory according to the order of low brightness. middle brightness and high brightness.
Note: the constant voltage dimmer output connect with LED. the upper limit must be coscade current-limiting resistance. Calculation Method of coscade current-limiting resistance: R = (Vi - Vled)/ Io Vi is the input voltage. Vled is the total pressure drop of all the LED lamps. Io is the total current light strings. Should consider the floating range Vi. Vled the calculation. Generally. when the battery is fully charged Vi will be too large. After the LED heat up. Vled will drop! Prevent excessive current from damaging modules or lights.
CH375B U-DISK Read Write Module USB interface communication SPI interface New in chennai
Description:
USB interface in the current electronic products accounted for a very large share of the microcontroller with USB interface communication direction of one of the most popular microcomputer application master chip module using the CH375, CH375 is a USB bus interface chip to support USB-The hOST and USB-DEVICE/SLAVE equipment the way. Locally, CH375 with 8-bit data bus and read, write, chip select control lines and interrupt output can be easily attached to the system bus of the microcontroller/DSP/MCU/MPU controller. USB host mode, CH375 also provides serial communication via serial input, serial output, and interrupt output monolithic/DSP/MCU/MPU connected.
CH375 USB device mode is fully compatible with CH372, CH375 contains all the features of the CH372. Common CH375 USB host mode support USB full-speed device, external microcontroller can through the the CH375 in accordance with the USB protocol and USB device communication. CH375 firmware also built a dedicated protocol processing Mass-Storage mass storage devices, external microcontroller can be directly used as the basic unit of reading and writing in sectors USB storage devices (including USB hard disk/USB flash drive/U disk).
Specs:
- 1. 2x8 connector, easy with the MCU mount.
- 2. Jumper selectable, can work in parallel or serial mode.
- 3. USB status indicator.
- 4. Onboard 3.3V LDO 1117, provides 800mA current.
- 5. 5V power supply is powered from the target board.
- 6. 12MHZ crystal.
- 7. PCB size: 30.16MM * 47.50MM
Duinopeak 68mm 16-Bit WS2812 5050 RGB LED Smart RGB Ring for Arduino in chennai
Features & Specifications:
Voltage DC 4~7V; Communication interface single line; LED drive chip ws2812B integrated LED; RGB wave length R 635~700nm, G 490~560nm, B 450~490nm; 16 PCS high bright smart LED NeoPixels arranged in round 68mm PCB; Those annulus RGB light can be simple connect one input pin to another (DI--DO) through output pin cascade; Though cascade, just use one pin of singlechip, you can control LED light as many as possible; Each LED integrated by one piece drive chip become smart and addressable; Each LED has 18mAh constant current drive, so the color will be same. Even though voltage changing is the same, no external resistance needed, the current-limiting resistance make RGB integrated design become slim. Use 5V power supply (working current 4~7V) drive RGB lamp ring.
DC-DC - CCCV Buck Boost in chennai
Features & Specifications:
- This module is a high-efficiency step-up/down regulator automatically modules .
- The efficiency in step up mode is 90%(INPUT 12V OUTPUT 19V/2A ),and the efficiency in setp down mode is 88%.
- Wide input voltage range : 6 ~ 35V
- Output voltage: can be adjusted between 1 ~ 35V
- Maximum Output Current : 5A,(long hours , please leave a certain margin ).
- Maximum Input Current : 7A,(Working long hours , please leave a certain margin ).
- Built in current limit function?0.1A-5A?
- Operating Frequency : 120KHz
HB100 Microwave Doppler Radar Detector Probe Wireless Sensor Module 10.525GHz in chennai
Description:
- 1.Type: Microwave Sensor
- 2.Chip: HB100
- 3.Frequency: 10.525GHz
- 4.Voltage: DC 5V 0.25V
- 5.Current: 40mA
- 6.Size length 37mm *width 45mm *height 8mm
Mini DC Adjustable Power Supply Buck Module Step Down Module in chennai
Description:
- Module Properties: Non-isolated step-down module (BUCK)
- Rectification: Synchronous rectification
- Input voltage: DC 4.75V-23V
- Output voltage: DC 1.0V-17V (Adjustable, Output < Input)
- Output current: Rated current 1.8A (3A MAX, can not be prolonged)
- Output ripple: 30mV (no-load)
- Dimension: 17 x 11 x 4mm(L x W x H) / 0.67'' x 0.43'' x 0.16'' approx
- Weight: 1g (per.)
MP3 Format Audio Player U Disk TF Card Amplifier Decoder Board Module arduino in chennai
Product Description:-
- Superior sound quality.
- Onboard 2W mono amplifier(5V power of up to 3W) is directly connected to the speaker (recommendation 4Ω 3W speakers)
- 3.5mm gold plated headphone jack can connect with headphones or external audi.
- With a micro USB port, through the mobile phone data line can use mobile power supply or the USB cable to charge the MP3 battery, also can use 3.7V lithium battery or USB 5V power supply to charge.
- Support TF card (mobile phone memory card) and U disk play mode.
- No soldering with speaker terminals for easy wiring.
- The module is designed to facilitate modification.
Specification:
- Material: Plactic and metal
- Size: Approx. 50*35*10mm / 1.97*1.38*0.39inch
Key Operating Instructions:
- "Prev / V--" button: "Press" for switching previous song, "long press" for volume down
- "Next/v++" button: "Press" for switching next song, "long press" for volume up.
- "P / P / Mode" button: "Press" for the "Play/Pause" Switch, "long press" for U disk, TF card mode.
- "Repeat" button: "Press" for “single/all song" mode(no long press)
New Tilt Sensor Module Tilt Switch Angle sensor For RASPBERRY PI ARDUINO AVR PIC in chennai
Application:
Tilt variety of products, dumping trigger an alarm, dumping off the sensor, tilt sensor. Tire Pressure Monitoring System (TPMS), bicycle lights, digital photo frame rotation, screen rotation, flip video camera, anti-theft systemTilt Sensor Module
Module Features:
using the highly sensitive switch SW-520D as the angle sensor. Comparator output signal clean waveform is good, driving ability, than 15mA. Working voltage 3.3V-5V
4 Pin OutputOutput format: Digital switching output (0 and 1) With bolt holes for easy installation Small plate PCB size Using a wide voltage LM393 comparator
PAM8406 - Mini 2x5W Class D Digital Amplifier Module in chennai
Features & Specifications:
Size:23*24MM Chip:PAM8406 Dual-channel stereo,only needed 5V power supply can input 5W+5W power,it can drive 4ohm,8ohm and left right channel volume adjustment. The unique non-LC filter Class-D digital power board, can be used computer USB to charge. Dual-panel wiring,can properly solve the ground potential balance and crosstalk between channels caused by wiring. Rated operating voltage is2.5-5V, the limited operating voltage is 5.5V Wiring:
PCA9685 16 Channel 12-bit PWM Servo motor Driver I2C Module For Arduino WC in chennai
Description
100% Brand New and High Quality You want to make a robot, When we saw this chip, we quickly realized what an excellent add-on this would be. Using only two pins, control 16 free-running PWM outputs! I2C input, control 16 PWM output, you can control the 16 way servo motor.
Specification
- Frequency: 40-1000Hz.
- Channel number: 16 channel.
- Resolution: 12 bit.
- Voltage: DC 5-10V
- Size: 60*25mm
- Color: blue
- Net Weight: 12 g
ULN2003 Stepper Motor Driver in chennai
Description
ULN2003 28BYJ-48 Stepper Motor Driver Board Module 5V 4-phase 5 line
Specification
- ULN2003A motor driver chip
- Chip all the pins already leads for easy connection to use
- XH-5P socket, can be connected directly 28BYJ-48 Model stepper motor
- 4-way signal indicator
- 5-12V power supply
- Technical parameters:
- Main Chip: ULN2003a
- Input Voltage: 5-12V power supply
HC-SR505 Mini Infrared PIR Motion Sensor Precise Infrared Detector Module in chennai
Introduction:
HC-SR505 small body sensing module is based on infrared technology, automatic control products, high sensitivity, high reliability, ultra-small, ultra-low-voltage operation mode. Widely used in various auto-sensing of electrical equipment, especially battery-powered automatic control products.
Specification
- Size: 40 x 10 x 13mm Net weight: 2g
Technical parameters:
- 1. Operating Voltage Range: DC4.5-20V
- 2. Static current: <60uA
- 3. Output level: High 3.3V / Low 0V
- 4. Trigger: repeatable trigger (default)
- 5. Delay time: Default 8S + -30%
- 6. PCB Dimensions: 10 x 23mm
- 7. Induction angle: <100 degree cone angle
- 8. Induction distance: 3 meters
- 9. Working temperature: -20 – +80 degrees
- 10. Sensor Lens Dimensions: Diameter: 10mm (default)
Features:
- 1. Automatic induction: to enter the sensing range of the output is high, people leave the sensor range automatically delay off high, output low. Ultra-small size.
- 2. Repeatable trigger: the sensor output high, the delay period, if there is human activity in its sensing range, the output will remain high until people leave after the high variable delay lOW (automatically extended sensor module detects the human body after every activity a delay period, and the last time an event is the starting point of the delay time).
- 3. Wide operating voltage range: the default operating voltage DC4.5V-20V.
- 4. Micropower: quiescent current <50 microamps, especially for battery-powered automatic control products.
- 5. Output high signal: easy docking and all kinds of circuits.
- Body induction lamps
- Body sensors toys
- Security Products
- Industrial automation and control
- Auto-sensing of electrical equipment
- Battery-powered automatic control
Applications:
4 Bits Digital Tube LED Display Module With Clock Display TM1637 for Ard Raspberry PI in chennai
Description
The module is a 12-foot clock with 4 points of positive digital (0.36 inches) display module driver IC TM1637, only two signal lines can make SCM four 8-segment LED.
Module features are as follows:
Display of male red for the four digital tube Adjustable digital tube 8 gray Level control interface for 5V or 3.3V 4 M2 screws positioning holes for easy installation 4 digital display interface module as shown below: Control Interface: A total of four pins (GND, VCC, DIO, CLK), GND to ground, VCC is the power supply, DIO of data input and output pin, CLK is the clock signal pin; Digital tube: 4 common anode score points with 0.36 inches LED, red highlights; Positioning holes: 4 M2 screws positioning hole diameter is 2.2mm, the positioning of the module is easy to install, to achieve inter-module combination;
VOLTAGE DIVIDER in chennai
The Voltage Divider provides an interface for measuring extern voltage, eliminating the need to connect a resistance to input interface. Besides, the voltage gain can select by dial switch. They are easy to use.
ARM LPC2148in chennai
The ARM LPC2148 Mini-Development Board can be used to experience the full capabilities of the NXP LPC2148 Microcontrollers. It is very much supportive in code development, debugging and prototyping to fully experience the power of ARMTDMI7 LPC2148 peripherals features. This board is used with varies break out boards and external peripherals for programming and ideally suitable for beginners, trainers and hobbyists. Since it is provided with male header to interface to varies modules, and circuits easily and also varies on-board power option (3.3V, 5V and 12V DC) for the components and device to be interfaced. DEVELOPMENT
M018 CH375B U-DISK Read Write Module USB interface communication SPI interface in chennai
Description
100% Brand new and high quality! CH375 is a USB bus interface chip to support USB-The hOST and USB-DEVICE/SLAVE equipment the way. CH375 with 8-bit data bus and read, write, chip select control lines and interrupt output can be easily attached to the system bus of the microcontroller/DSP/MCU/MPU controller. USB host mode, CH375 also provides serial communication via serial input, serial output, and interrupt output monolithic/DSP/MCU/MPU connected. 2x8 connector, easy with the MCU mount. Jumper selectable, can work in parallel or serial mode. USB status indicator. Onboard 3.3V LDO 1117, provides 800mA current. 5V power supply is powered from the target board. 12MHZ crystal. Specifications: PCB size: 48mm x 27mm Color: Blue
